Lead screw for table movement in Ram Turret milling machine Cross Feed Y-Axis Lead Screw-Turret mill M3-0027
Precision cross feed screw for Y-axis table movement in M3 Ram Turret milling machines. Converts rotational handwheel input into smooth linear saddle motion with minimal backlash. • 730 mm total length for standard M3 table size • ACME thread with 5 TPI pitch for stable feed • Alloy steel shaft with brass nut set included • Reduces backlash to ≤ 0.10–0.15 mm typical
Specifications
For: Cross Feed Y-Axis Lead Screw-Turret mill M3-0027- Product Name
- Lead screw / Cross feed Screw
- Compatible with Machine Model
- M3 (table size 1270x254 mm)
- Model
- D-0027
- Dimension
- 800x50x50 mm
- Weight
- 3.0 Kgs
- Axis Motion
- "Y" axis / Cross Axis
- Total length
- 730 mm
- Diameter
- 32 mm
- Thread Type
- ACME thread
- Thread Pitch
- 5 TPI
- Backlash (with new nut)
- ≤ 0.10–0.15 mm typical
- Material
- Alloy Steel
- Step Length
- 54 mm
- Thread Length Top
- 20 mm
- Item includes
- Lead screw and Brass nut set Suitable for Vertical Ram Turret Milling
Configurations
Click a row to switch| Variant | Compatible with Machine Model | Diameter | Item includes | Total length | Price |
|---|---|---|---|---|---|
| Cross Feed Y-Axis Lead Screw-Turret mill M3-0027 | M3 (table size 1270x254 mm) | 32 mm | Lead screw and Brass nut set Suitable for Vertical Ram Turret Milling | 730 mm | ₹14,700 |
| Z-Axis Lead Screw- Ram Turret mill M3/M4-C-0082 | M3/M4 (table size 1270x254/1370x254 mm) | 32 mm | Lead screw and Brass nut set Suitable for Vertical Ram Turret Milling | 580 mm | ₹15,700 |
| X-Axis Lead Screw Ram Turret mill M3-D-0015 | M3 (table size 1270x254 mm) | 32 mm | Lead screw and Brass nut set Suitable for Vertical Ram Turret Milling | 1530 mm | ₹15,400 |
| Cross Feed Y-Axis Lead Screw-Turret mill M4-0027 | M4 (table size 1370x254 mm) | 32 mm | Lead screw and Brass nut set Suitable for Vertical Ram Turret Milling | 730 mm | ₹14,900 |
| X-Axis Lead Screw Ram Turret mill M4-D-0015 | M4 (table size 1370x254 mm) | 32 mm | Lead screw and Brass nut set Suitable for Vertical Ram Turret Milling | 730 mm | ₹15,900 |
Features:
- Precision ACME-threaded lead screw
- High-strength alloy steel construction
- Hardened and ground for durability
- Smooth and accurate Y-axis movement
- Low backlash design when paired with a matching feed nut
- Machined ends for easy installation
- Corrosion-resistant finish
Description
This Cross Feed Screw is manufactured from hardened, high-strength alloy steel for long service life and stable performance. The screw features precision-cut threads for accurate linear displacement and smooth saddle travel. The design includes a machined end for connecting to a handwheel, dial, or power feed unit.
It is commonly used as a replacement part in Bridgeport-type milling machines, M1TR mills, and other vertical milling machines requiring Y-axis feed repair or maintenance.
Applications:
- Vertical turret milling machines
- Bridgeport-type milling machines
- M1TR (RAM-type) milling machines
- Machine restoration, service, and maintenance
- Replacement for worn or damaged Y-axis feed screws
Advantages:
- Improves machining accuracy
- Reduces saddle vibration and wear
- Ensures smooth table travel
- Increases machine reliability and lifespan
- Direct replacement part for many mills
Compatibility:
- Bridgeport Series 1 Type Mills
- M1TR Milling Machines
- Vertical Turret Mills (Asian Bridgeport-style)
- 4S / 3S Milling Machines
- Custom retrofitted milling tables
More questions buyers ask
What is a Y-axis cross feed lead screw?
It is a precision-threaded rod that converts rotational motion from the handwheel into linear movement for the Y-axis (cross-slide) of a milling machine.
Which machines are compatible with this lead screw?
This lead screw is designed for Bridgeport-type vertical turret milling machines, specifically M3 and M4 models.
What material is the lead screw made of?
It is constructed from high-strength, hardened alloy steel for superior durability and wear resistance.
Does the lead screw come with a nut?
Yes, each unit includes a matching brass feed nut to ensure low-backlash operation.
What is the thread type?
It features a precision ACME thread, which is the industry standard for power transmission in machine tools.
How do I maintain the lead screw?
Regular cleaning and lubrication with high-quality machine oil or grease are essential to maintain accuracy and prevent premature wear.
Can this be used for CNC retrofitting?
Yes, many users utilize these high-quality lead screws for manual-to-CNC conversion projects on Bridgeport-style mills.
What is the typical backlash?
When paired with a new matching nut, the backlash is typically ≤ 0.10–0.15 mm.
Is the lead screw hardened?
Yes, the screw is hardened and ground to ensure smooth, accurate movement and a long service life.
Do you provide GST invoices?
Yes, all purchases include a valid GST invoice for business accounting purposes.
Who should choose the M3-compatible lead screw?
Choose this if you own a standard M3 turret milling machine with a 1270x254 mm table and require a direct, high-quality replacement for the Y-axis.
Who should choose the M4-compatible lead screw?
Choose this if you operate an M4 turret milling machine with a larger 1370x254 mm table and need a specific fit for the Y-axis cross feed.
How does the Y-axis screw differ from the X-axis screw?
The Y-axis screw is shorter and designed for cross-slide movement, whereas the X-axis screw is significantly longer to accommodate longitudinal table travel.
Why choose Pentagon over generic replacements?
Pentagon lead screws are manufactured with precision-ground ACME threads and high-strength alloy steel, offering better accuracy and longevity than generic alternatives.
