Toolvisor TCT Core Drill Cutter 36-56mm x 75mm Depth — 36X75MM
Core Drill TCT Cutter (18-35 mm range) is a precision-engineered hole cutting tool designed for small to medium diameter drilling in metal, delivering fast cutting speed, high accuracy, and extended tool life with durable tungsten carbide tipped edges.
Specifications
For: 36X75MM- shank type
- Universal fitting cutter shank
- Art no
- TCL75.360
- Max Tensile Strength
- <1200RM(N/mm2)
- Cutting Geometry
- Triple Tooth
- Application Material
- Mild Steel, Stainless Steel, Alloy Steel, Aluminium
- Cutter Size
- 36MM
- Cutting Depth
- 75 mm
Configurations
Click a row to switch| Variant | Cutter Size | Cutting Depth | Application Material | Price |
|---|---|---|---|---|
| 36X75MM | 36MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹3,980 |
| 37X75MM | 37MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹3,980 |
| 38X75MM | 38MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹3,980 |
| 39X75MM | 39MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹3,980 |
| 40X75MM | 40MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹3,980 |
| 41X75MM | 41MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹4,560 |
| 42X75MM | 42MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹4,560 |
| 43X75MM | 43MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹4,560 |
| 44X75MM | 44MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹4,560 |
| 45X75MM | 45MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹4,560 |
| 46X75MM | 46MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹5,540 |
| 47X75MM | 47MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹5,540 |
| 48X75MM | 48MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹5,540 |
| 49X75MM | 49MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹5,540 |
| 50X75MM | 50MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹5,540 |
| 51X75MM | 51MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹6,360 |
| 52X75MM | 52MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹6,360 |
| 53X75MM | 53MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹6,360 |
| 54X75MM | 54MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹6,360 |
| 55X75MM | 55MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹6,360 |
| 56X75MM | 56MM | 75 mm | Mild Steel, Stainless Steel, Alloy Steel, Aluminium | ₹6,360 |
Operational Efficiency
- Reduces production time through high-speed cutting capability
- Minimizes post-processing due to clean hole finishes
- Lowers cost per hole with extended carbide edge life
- Improves safety by reducing manual handling of heavy tools
- Enhances overall workflow in metal fabrication shops
Magnetic Drill Integration
- Specifically designed for use with Magnetic Drill Machines
- Provides stable anchoring to reduce operator fatigue
- Maintains vertical alignment for perpendicular hole placement
- Ideal for on-site fabrication and heavy machinery maintenance
- Reduces setup time compared to traditional drill presses
Shank and Depth Specifications
- Features a secure Weldon Shank for stable magnetic mounting
- Supports a cutting depth of 75 mm for deep hole applications
- Fits within the 36–56 mm cutter size range for flexibility
- Ensures rigid connection to prevent vibration during drilling
- Optimized geometry for smooth chip evacuation
Material Compatibility
- Effective on Mild Steel for general structural fabrication
- Cuts Stainless Steel with minimal tool wear and heat
- Handles Alloy Steel drilling with consistent performance
- Compatible with Aluminium for lightweight construction work
- Versatile solution for diverse industrial metal types
Precision Cutting Performance
- Engineered with durable tungsten carbide tipped edges
- Delivers fast cutting speed for efficient metal removal
- Ensures high accuracy for precise hole cutting operations
- Designed for extended tool life in demanding environments
- Suitable for small to medium diameter drilling applications
Frequently asked
What is the maximum cutting depth?
This cutter supports a cutting depth of 75 mm.
Which materials can this TCT cutter handle?
It works on Mild Steel, Stainless Steel, Alloy Steel, and Aluminium.
What shank type is compatible?
It features a Weldon Shank for magnetic drill compatibility.
More questions buyers ask
What is a TCT annular cutter?
A Tungsten Carbide Tipped (TCT) annular cutter is a specialized drill bit for creating clean, accurate holes in metal. It only cuts the periphery of the hole, saving time and energy compared to traditional twist drills.
What are the main advantages of using a Toolvisor TCT cutter?
Toolvisor TCT cutters offer high-speed drilling, long service life due to their durable carbide tips, and superior hole finish. They are designed for use with magnetic drill presses for stability and precision.
What materials can I drill with this TCT cutter?
These cutters are effective on a wide range of materials, including Mild Steel, Stainless Steel, Alloy Steel, and Aluminium.
What is a Weldon shank?
A Weldon shank is a standard type of shank for annular cutters, featuring two flat sides for secure clamping in a magnetic drill's arbor, preventing slippage during operation.
What is the cutting depth of these Toolvisor cutters?
All variants in this series have a maximum cutting depth of 75mm.
Do I need a pilot pin?
Yes, a pilot pin is essential. It helps in centering the cutter on the drilling point and ejects the cut slug after the hole is complete.
Is there a warranty on these cutters?
Yes, we offer a 6-month warranty against manufacturing defects. Please note that this does not cover wear and tear from normal use.
Can I get a GST invoice for my purchase?
Absolutely. We provide a GST invoice for all B2B purchases, allowing you to claim input tax credit.
Do you deliver across India?
Yes, we offer pan-India delivery to all major cities and industrial areas.
How do I choose the right cutter size?
Select the cutter size based on the final hole diameter you require. This series ranges from 36mm to 56mm.
Who should choose the 36X75MM TCT Cutter?
The 36mm variant is ideal for fabricators and engineers needing to create small-to-medium diameter holes with high precision. It's a great entry-point for general-purpose metal drilling tasks.
Who should choose the 45X75MM TCT Cutter?
The 45mm cutter is suited for medium-heavy fabrication jobs requiring a balance of size and speed. It's a popular choice for structural steel work and equipment maintenance.
Who should choose the 56X75MM TCT Cutter?
The 56mm variant is the largest in this series, designed for heavy-duty applications in construction, shipbuilding, and large machinery repair where creating large, clean bores is critical.
What is the difference between the 36mm, 45mm, and 56mm cutters?
The primary difference is the cutting diameter. The 36mm is for smaller holes, the 45mm for mid-range applications, and the 56mm for the largest diameter jobs. While all have a 75mm depth, the price increases with the diameter.
How does cutter size affect drilling speed?
Generally, smaller diameter cutters can be run at a higher RPM (Revolutions Per Minute) than larger cutters. Always consult the speed chart for your specific magnetic drill machine and the material you are cutting for optimal performance and tool life.
Are the prices different for each cutter size?
Yes, the price of the TCT cutter increases as the diameter gets larger. The variants are grouped into price tiers based on their size.
More like this
Full description
Core Drill TCT Cutter (18-35 mm range) is a precision-engineered hole cutting tool designed for small to medium diameter drilling in metal, delivering fast cutting speed, high accuracy, and extended tool life with durable tungsten carbide tipped edges.
