SLIDE GUIDE — SWC 50 MAX-T MAGNETIC FRAME
Slide guide is a precision mechanical component used in machines to ensure smooth and controlled linear movement of the motor or drilling assembly. It helps maintain proper alignment during operation, reducing vibration and wear while improving accuracy. Built from durable metal with a finely machined surface, the slide guide provides stable support and reliable motion in magnetic drilling machines like SWC models.
Specifications
For: SWC 50 MAX-T MAGNETIC FRAME- Application
- Magnetic drilling machine
- Compatibility
- SWC models
- Function
- Guides linear movement
- Movement Type
- Sliding
- Fitment
- Precision machined
- Strength
- High load bearing
- Alignment
- Maintains accurate positioning
- Installation
- Fixed mount
- Maintenance
- Low maintenance
- Article no
- 00716841489835
- Dimentions
- 116X27X285
Configurations
Click a row to switch| Variant | Article no | Dimentions | Maintenance | Price |
|---|---|---|---|---|
| SWC 50 MAX-T MAGNETIC FRAME | 00716841489835 | 116X27X285 | Low maintenance | ₹1,996 |
| SWC 65 MAGNETIC FRAME | 00716841490961 | 116X27X285 | Low maintenance | ₹2,811 |
| SWC 65 WT MAGNETIC FRAME | 00716841492088 | 116X27X285 | Low maintenance | ₹2,811 |
| SWC 80 MAGNETIC FRAME | 00716841493054 | 116X27X285 | Low maintenance | ₹2,811 |
| SWC 80 WT MAGNETIC FRAME | 00716841494013 | 116X27X285 | Low maintenance | ₹2,811 |
| SWC 100 MAGNETIC FRAME | 00716841494983 | 385X20.5 | Low maintenance | ₹3,637 |
| SWC 100 WT MAGNETIC FRAME | 00716841495942 S | 385X20.5 | Low maintenance | ₹3,637 |
| SWC 120 WT MAGNETIC FRAME | 00716841497144 | 16X27X285 | Low maintenance | ₹3,155 |
| SWC 50 PD MAGNETIC FRAME | 00716841499179 | 16X27X285 | Low maintenance | ₹2,811 |
| SWC 50 PDT MAGNETIC FRAME | 00716841500295 | 16X27X285 | Low maintenance | ₹2,811 |
Operational Benefits
- Improves drilling accuracy by maintaining strict alignment
- Prevents unnecessary wear on the motor or drilling assembly
- Provides stable support for consistent performance
- Simplifies maintenance schedules with reliable components
- Reduces downtime through reliable motion support
- Increases productivity with controlled linear movement
- Supports high load bearing requirements effectively
Compatibility & Applications
- Ideal for magnetic drilling machines requiring precision
- Specifically compatible with SWC models in the market
- Supports drilling assembly movement in industrial settings
- Enhances overall machine accuracy during linear tasks
- Suitable for environments requiring reduced vibration levels
- Application defined as magnetic drilling machine use
- Movement type confirmed as sliding mechanism
Construction & Durability
- Built from durable metal to withstand heavy usage
- Finely machined surface ensures minimal friction
- Designed for stable support during high-torque operations
- Robust construction minimizes alignment drift over time
- Engineered to handle consistent sliding movement types
- Standard dimension reference 1 for general sizing
- Optimized for durability in industrial environments
Key Features & Functionality
- Ensures smooth and controlled linear movement for motor assemblies
- Maintains accurate positioning during drilling operations
- High load bearing strength for demanding industrial tasks
- Precision machined fitment for reliable motion stability
- Fixed mount installation design for secure attachment
- Reduces vibration and wear to extend machine life
- Low maintenance requirement for continuous operation
- Article no 0 identifies this specific product variant
Frequently asked
What type of movement does this guide support?
It is designed for sliding movement types within the machine.
Is this compatible with all magnetic drilling machines?
It is specifically compatible with SWC models.
How difficult is the installation process?
It features a fixed mount design for straightforward installation.
What is the maintenance requirement for this guide?
It requires low maintenance for continuous operation.
More questions buyers ask
What is the function of a slide guide in a magnetic drilling machine?
The slide guide ensures smooth, precise linear movement of the drilling assembly, which is crucial for maintaining accuracy and reducing wear and tear on the machine.
Is this an original Schifler spare part?
Yes, this is a genuine Schifler slide guide, designed for perfect compatibility with SWC series magnetic drilling machines.
What is the warranty on the Schifler slide guide?
This spare part comes with a 6-month warranty against manufacturing defects. We provide a GST invoice for all purchases.
Do you deliver across India?
Yes, we offer pan-India delivery for the Schifler slide guide. Your order will be securely packaged and shipped to your location.
How do I know which slide guide is right for my machine?
This slide guide is available for a range of Schifler SWC models. Please select the variant that matches your machine's model number (e.g., SWC 50, SWC 65, etc.) from the options on the product page.
Who should choose the SWC 50 MAX-T MAGNETIC FRAME?
This slide guide is specifically for the Schifler SWC 50 MAX-T magnetic drill. It's the ideal choice for users of this model who need to replace a worn or damaged slide guide to restore the machine's original precision.
Who should choose the SWC 65 MAGNETIC FRAME?
This is the correct slide guide for the Schifler SWC 65 model. Choose this to ensure perfect fitment and smooth operation for your SWC 65 magnetic drill.
Who should choose the SWC 65 WT MAGNETIC FRAME?
Select this slide guide if you own the Schifler SWC 65 WT magnetic drill. It is engineered to the exact specifications of the SWC 65 WT for optimal performance.
Who should choose the SWC 80 MAGNETIC FRAME?
This slide guide is designed for the Schifler SWC 80 magnetic drill. It's the right part to maintain the accuracy and longevity of your SWC 80 machine.
Who should choose the SWC 80 WT MAGNETIC FRAME?
For owners of the Schifler SWC 80 WT magnetic drill, this is the designated slide guide. It ensures your machine operates with its original factory precision.
Who should choose the SWC 100 MAGNETIC FRAME?
This slide guide is the correct replacement part for the Schifler SWC 100 magnetic drill, ensuring it continues to perform with high precision.
Who should choose the SWC 100 WT MAGNETIC FRAME?
If you use the Schifler SWC 100 WT model, this is the slide guide you need. It guarantees a perfect fit and restores the machine's smooth linear motion.
Who should choose the SWC 120 WT MAGNETIC FRAME?
This is the specific slide guide for the heavy-duty Schifler SWC 120 WT magnetic drill. It's essential for maintaining the performance of this powerful machine.
Who should choose the SWC 50 PD MAGNETIC FRAME?
Choose this slide guide if you have the Schifler SWC 50 PD magnetic drill. It's the genuine replacement part to ensure continued accuracy and reliability.
Who should choose the SWC 50 PDT MAGNETIC FRAME?
This slide guide is manufactured for the Schifler SWC 50 PDT magnetic drill. It's the correct component to maintain your machine's precise drilling capabilities.
What is the difference between the slide guides for the SWC 50, SWC 65, and SWC 80 models?
The primary difference is the specific model compatibility. Each slide guide is manufactured to the exact dimensions and tolerances of the corresponding machine (SWC 50, SWC 65, SWC 80, etc.) to ensure a perfect fit and optimal performance. Always choose the guide that matches your machine's model number.
Are the 'WT' model slide guides different from the standard ones?
Yes. The slide guides for 'WT' (Weldon Shank Tapping) models like the SWC 65 WT or SWC 80 WT are designed to accommodate the specific frame and assembly of those machines. It is important to select the 'WT' variant if you have a 'WT' model drill.
How do I choose between the SWC 100 and SWC 120 WT slide guides?
The choice depends entirely on your machine model. The SWC 100 slide guide fits the SWC 100 and SWC 100 WT models, while the SWC 120 WT guide is exclusively for the SWC 120 WT machine. Check your machine's model number before purchasing.
