Magnet Base
A magnet base is a sturdy mounting device that uses a powerful permanent magnet to securely attach measuring instruments—such as dial indicators or test indicators—to metal surfaces. It typically features an on/off magnetic switch, adjustable arms or joints for precise positioning, and a rigid structure to minimize vibration. Magnet bases are widely used in machining, inspection, and alignment tasks to hold instruments firmly in place while taking accurate measurements.
Specifications
For: SWC 35 H MOTOR- Base type
- Magnetic
- Corrosion resistance
- Yes
- Fine adjustment
- Yes
- size
- 167*83*24MM
Operational Efficiency and Reliability
- Reduces setup time with rapid magnetic engagement and disengagement
- Enhances measurement reliability by eliminating hand-held instability
- Compatible with standard measuring tools across various industrial sectors
- Ergonomic design reduces operator fatigue during prolonged inspection cycles
- Secure hold prevents damage to sensitive instruments during movement
Construction Quality and Durability
- Heavy-duty steel body provides stability during high-tolerance measurements
- Multi-axis arm design allows flexible positioning around complex geometries
- High-grade magnetic material maintains holding power over extended use
- Smooth adjustment joints prevent tool slippage under load
- Protective coating guards against oil, coolant, and workshop contaminants
Industrial Applications and Use Cases
- Ideal for holding dial indicators during precision machining operations
- Supports inspection tasks requiring stable mounting on metal workpieces
- Essential for alignment procedures in assembly and maintenance workflows
- Facilitates accurate measurement while holding instruments firmly in place
- Suitable for workshop environments where vibration resistance is critical
Core Features and Capabilities
- Powerful permanent magnet ensures secure attachment to ferrous surfaces
- On-off magnetic switch allows quick release and repositioning of tools
- Fine adjustment capability enables precise positioning of measuring instruments
- Corrosion-resistant construction extends tool life in demanding environments
- Rigid structure minimizes vibration for consistent measurement accuracy
Frequently asked
Can this magnet base be used on non-metal surfaces?
No, it requires a ferrous metal surface for magnetic attraction to function.
How do I maintain the magnetic strength over time?
Keep the magnet switch in the off position when not in use to preserve power.
Is it compatible with all dial indicators?
Yes, the standard mounting interface fits most common industry measuring tools.
More questions buyers ask
What is a Schifler Magnet Base used for?
The Schifler Magnet Base is a sturdy mounting device used to securely attach measuring instruments like dial indicators to metal surfaces for precision machining, inspection, and alignment tasks.
What are the dimensions of this magnet base?
This particular model has a base size of 167mm x 83mm x 24mm.
Is the magnet switch easy to operate?
Yes, it features a simple on/off switch to engage and disengage the powerful permanent magnet, allowing for quick and easy positioning.
Can this base be used with any brand of dial indicator?
Yes, it is designed with a universal mount that is compatible with most standard dial and test indicators.
Is this product covered by a warranty?
Yes, all Schifler products sold by us come with a manufacturer's warranty. We also provide a GST invoice for your purchase.
How do I ensure the longevity of the magnet?
To preserve the magnetic strength, it is recommended to keep the magnet switch in the 'off' position when the base is not in use.
What is the material of the base?
It is constructed from a heavy-duty steel body to provide maximum stability and durability during high-tolerance measurements.
Do you offer pan-India shipping?
Yes, we offer fast and reliable pan-India delivery for all our products.
Can I get a GST invoice for my purchase?
Absolutely. We provide a GST-compliant invoice with every order for your accounting and tax credit needs.
Who should choose the Schifler Magnet Base SWC 35 H Motor variant?
This variant is ideal for professionals and workshops that require a reliable and strong magnetic base for frequent and precise measurement tasks in machining, fabrication, and quality control. Its specific 'SWC 35 H MOTOR' designation suggests it is part of a system, likely paired with a drilling machine, making it suitable for integrated workshop setups.
How does the Schifler Magnet Base compare to other brands?
Schifler is known for its German engineering heritage, offering a balance of high-quality construction, strong magnetic force, and durability at a competitive price point for the Indian B2B market.
What is the difference between a magnetic base and a standard clamp?
A magnetic base offers much faster setup and repositioning on ferrous metal surfaces compared to mechanical clamps. It also provides a more stable, vibration-resistant hold for sensitive measuring instruments.
Is a larger magnet base always better?
Not necessarily. While a larger base may offer a stronger hold, the ideal size depends on your application, the space available on your workpiece, and the instrument you are mounting. This 167x83x24mm base offers a strong hold in a relatively compact footprint.
