Schifler HSS Annular Cutter 43x50 mm
Schifler HSS Annular Cutter for magnetic drill machines delivers fast, precise core drilling in mild steel, stainless steel, alloy steel, and aluminium. This 43 mm diameter tool with a 50 mm cutting depth removes only the outer material ring for efficient power usage and smooth holes. • Diameter: 43 mm • Cutting Depth: 50 mm • Shank Size: 19.05 mm (3/4") • Shank Type: Weldon Shank
Specifications
For: 43x50 mm- Product Name
- HSS Annular Cutter
- Application Material
- Mild Steel, Stainless Steel, Alloy Steel, Aluminium
- Suitable Machine
- Magnetic Drill Machine
- Cutter Size
- 43 mm
- Cutting Depth
- 50 mm
- Shank Size
- 19.05 mm (3/4")
- Shank Type
- Weldon Shank
Configurations
Click a row to switch| Variant | Cutter Size | Cutting Depth | Shank Size | Shank Type | Price |
|---|---|---|---|---|---|
| 43x50 mm | 43 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹3,797 |
| 45x50 mm | 45 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹4,175 |
| 46x50 mm | 46 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹4,175 |
| 47x50 mm | 47 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹4,500 |
| 48x50 mm | 48 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹4,500 |
| 49x50 mm | 49 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹4,735 |
| 50x50 mm | 50 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹4,735 |
| 51x50 mm | 51 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹5,340 |
| 52x50 mm | 52 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹5,340 |
| 53x50 mm | 53 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹5,671 |
| 54x50 mm | 54 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹5,671 |
| 55x50 mm | 55 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹6,020 |
| 56x50 mm | 56 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹6,020 |
| 57x50 mm | 57 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹6,338 |
| 58x50 mm | 58 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹6,338 |
| 59x50 mm | 59 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹6,671 |
| 60x50 mm | 60 mm | 50 mm | 19.05 mm (3/4") | Weldon Shank | ₹6,671 |
Operational Safety & Maintenance
- Requires adequate coolant or lubricant to prevent overheating
- Inspect cutting teeth regularly for wear or chipping
- Store in dry conditions to prevent rust on HSS surfaces
- Ensure magnetic base is clean and level before operation
- Follow manufacturer torque limits for optimal tool life
Optimized Cutting Depth Range
- Supports a maximum cutting depth of 50 mm per pass
- Covers the 43-60 mm diameter range for versatile hole sizes
- Allows deep penetration without frequent retraction
- Enhances productivity on thick plate fabrication tasks
- Reduces setup time compared to twist drill alternatives
Precision Shank Design
- Features a standard 19.05 mm (3/4") Weldon shank
- Ensures secure, slip-free mounting in magnetic drill chucks
- Compatible with major brands of magnetic drilling machines
- Simplifies tool changeover for maintenance teams
- Reduces vibration during high-speed rotation operations
Versatile Material Compatibility
- Ideal for cutting mild steel and structural carbon steels
- Effective on stainless steel grades including 304 and 316
- Capable of drilling alloy steel components with precision
- Suitable for non-ferrous materials like aluminium
- Handles a wide range of industrial metal thicknesses
High-Performance HSS Construction
- Manufactured from high-speed steel for superior heat resistance
- Maintains sharp cutting edges during prolonged industrial use
- Optimized geometry ensures efficient chip evacuation
- Designed to withstand high torque loads on magnetic drills
- Provides consistent performance across various metal alloys
More questions buyers ask
What is an HSS annular cutter?
An HSS annular cutter is a specialized drill bit designed for magnetic drilling machines, used to cut clean, precise holes in metal by removing only the periphery of the hole.
What is the cutting depth of these Schifler cutters?
These Schifler HSS annular cutters have a standard cutting depth of 50 mm.
What shank type do these cutters use?
They feature a standard 19.05 mm (3/4") Weldon shank, ensuring compatibility with most magnetic drill machines.
Can these cutters be used on stainless steel?
Yes, they are effective on various materials including mild steel, stainless steel (304/316), alloy steel, and aluminium.
Do I need a pilot pin?
Yes, a pilot pin is recommended to center the cutter, control coolant flow, and eject the slug after drilling.
How do I maintain my annular cutter?
Use adequate coolant, inspect teeth for wear, store in a dry place, and ensure the magnetic base is clean before operation.
Are these cutters suitable for heavy-duty fabrication?
Yes, they are designed for demanding industrial environments like bridge construction, shipbuilding, and structural steel projects.
What is the advantage of an annular cutter over a twist drill?
Annular cutters cut faster, require less power, and produce cleaner holes with less material waste compared to twist drills.
What diameter range is covered by this product series?
This series covers diameters from 43 mm to 60 mm.
Is a GST invoice provided?
Yes, all purchases include a GST invoice for business accounting.
Who should choose the 43 mm cutter?
The 43 mm cutter is ideal for fabricators needing precise, smaller diameter holes in structural steel plates.
Who should choose the 60 mm cutter?
The 60 mm cutter is best for heavy-duty industrial projects requiring large diameter holes in thick metal components.
How do 43-50mm cutters compare to 51-60mm cutters?
The 43-50mm range is suited for standard fabrication tasks, while the 51-60mm range is designed for heavy-duty, large-scale industrial drilling.
Are these cutters compatible with all magnetic drills?
They are compatible with most magnetic drilling machines that accept a standard 19.05 mm (3/4") Weldon shank.
