Schifler HSS Annular Cutter 12-60mm | Buy Online Price in India — 12x35mm
Engineered for precision hole making, these HSS Annular Cutters deliver efficient core drilling on magnetic drill machines. Designed to remove only the outer ring of material, they ensure smooth, burr-free cuts with reduced power consumption across various steel types. • Compatible with Mild Steel, Stainless Steel, and Alloy Steel • Weldon Shank design ensures secure grip during high-torque operations • Optimized for 35 mm cutting depth applications • Ideal for fabrication and steel work
Specifications
For: 12x35mm- SIze
- 12 mm
- Cutting depth
- 35 mm
- Product Name
- HSS Annular Cutter
- Shank Type
- Weldon Shank
- Shank Size
- 19.5 mm (3/4")
- Application Material
- Mild Steel, Stainless Steel, Alloy Steel, Aluminium
- Suitable Machine
- Magnetic Drill Machine
Configurations
Click a row to switch| Variant | Cutting depth | SIze | Shank Size | Shank Type | Price |
|---|---|---|---|---|---|
| 12x35mm | 35 mm | 12 mm | 19.5 mm (3/4") | Weldon Shank | ₹1,120 |
| 13x35 mm | 35 mm | 13 mm | 19.5 mm (3/4") | Weldon Shank | ₹1,120 |
| 13.5x35 mm | 35 mm | 13.5 mm | 19.5 mm (3/4") | Weldon Shank | ₹1,135 |
| 14x35 mm | 35 mm | 14 mm | 19.5 mm (3/4") | Weldon Shank | ₹1,135 |
| 14.5x35 mm | 35 mm | 14.5 mm | 19.5 mm (3/4") | Weldon Shank | ₹1,135 |
| 15x35 mm | 35 mm | 15 mm | 19 .5 mm (3/4") | Weldon Shank | ₹1,135 |
| 15.5x35 mm | 35 mm | 15.5 mm | 19.5 mm 93/4") | Weldon Shank | ₹1,180 |
| 16x35 mm | 35 mm | 16 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,180 |
| 16.5x35 mm | 35 mm | 16.5 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,180 |
| 17x35 mm | 35 mm | 17 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,180 |
| 17.5x35 mm | 35 mm | 17.5 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,242 |
| 18x35 mm | 35 mm | 18 mm | 19.5 mm (3/4") | Weldon Shank | ₹1,242 |
| 18.5x35 mm | 35 mm | 18.5 mm | 19.5 mm (3/4") | Weldon Shank | ₹1,242 |
| 19x35 mm | 35 mm | 19 mm | 19.5 mm (3/4") | Weldon Shank | ₹1,242 |
Machine Compatibility
- Widely used with magnetic drilling machines for stability
- Compatible with radial drilling machines and drill presses
- Secure shank fitting prevents slippage during high torque
- Optimized for use in workshops and fabrication units
- Ensures reliable performance in heavy engineering environments
- Works with 19 mm – 25 mm Shank Size options for compatibility
Industrial Applications
- Steel fabrication and structural engineering work
- Bridge construction and railway fabrication projects
- Shipbuilding and heavy engineering industries
- Drilling operations using magnetic drilling machines
- Industrial maintenance and repair work in workshops
- Manufacturing plants and machine shop operations
- Construction and infrastructure projects requiring precision
Material Compatibility
- Ideal for drilling in mild steel, stainless steel, and alloy steel
- Suitable for aluminium and other common metal surfaces
- Handles various metals used in fabrication and industrial applications
- Effective on structural plates and heavy engineering components
- Maintains sharpness across different metal hardness levels
Performance & Efficiency Benefits
- Faster drilling speeds compared to conventional twist drills
- Reduced cutting resistance results in lower power consumption
- Produces clean holes with minimal burr formation
- Core cutting design minimizes material waste and removal
- Enables faster drilling operations improving overall work efficiency
- High drilling efficiency for fast and precise hole making
- Requires less power due to efficient cutting geometry
Precision Construction & Design
- Manufactured from premium High Speed Steel (HSS) for durability
- Features 35 mm cutting depth suitable for medium thickness materials
- Available in 12 mm Size with 19 mm – 25 mm Shank Size options
- Weldon Shank Design ensures secure and stable fitting in machines
- Precision Ground Cutting Edges provide accurate and smooth hole finishing
- Robust construction withstands demanding working conditions
- Excellent heat and wear resistance for longer tool life
Frequently asked
What material is the cutter made from?
It is manufactured from premium High Speed Steel (HSS).
Which machines are compatible with this cutter?
Works effectively with magnetic drills, radial drills, and drill presses.
What is the cutting depth capability?
Available with 35 mm cutting depth for medium thickness materials.
More questions buyers ask
What is an HSS annular cutter used for?
It is used for fast, precise hole making in metal by removing only the outer ring of material, leaving a solid core.
What materials can this cutter drill through?
It is ideal for drilling in mild steel, stainless steel, alloy steel, and aluminium.
Which machines are compatible with this cutter?
It works effectively with magnetic drilling machines, radial drills, and drill presses.
What is the shank type of this cutter?
It features a standard Weldon Shank (19.05mm or 3/4 inch) for secure fitting and to prevent slippage.
What cutting depths are available?
These Schifler cutters are available in 35 mm and 50 mm cutting depths.
Does it require a pilot pin?
Yes, using a pilot pin is recommended to center the cutter, control coolant flow, and eject the slug after drilling.
How does an annular cutter compare to a twist drill?
It cuts faster and requires less power because it only cuts the periphery of the hole, unlike a twist drill which converts the entire hole into chips.
Can it be resharpened?
Yes, High Speed Steel (HSS) annular cutters can be resharpened multiple times to extend their tool life.
Is coolant necessary when using this cutter?
Using a high-quality cutting fluid or coolant is highly recommended to improve tool life, cutting speed, and hole finish.
What sizes are available in this range?
The Schifler HSS annular cutters are available in a wide range of sizes from 12 mm up to 60 mm in diameter.
Who should choose the 12x35mm HSS Annular Cutter?
It is ideal for fabricators needing small, precise 12mm holes in metal plates up to 35mm thick.
Who should choose the 20x35mm HSS Annular Cutter?
Perfect for structural engineering work requiring standard 20mm holes with a 35mm depth capacity.
Who should choose the 50x35mm HSS Annular Cutter?
Best for heavy engineering applications needing large 50mm diameter holes in standard plates.
Who should choose the 12x50mm HSS Annular Cutter?
Suitable for deep drilling applications requiring a 12mm hole through materials up to 50mm thick.
Who should choose the 25x50mm HSS Annular Cutter?
Ideal for heavy-duty fabrication requiring 25mm holes in thick steel sections up to 50mm.
What is the difference between the 35mm and 50mm cutting depth variants?
The 35mm variants are designed for standard plate thicknesses, while the 50mm variants allow drilling through thicker materials or multiple stacked plates.
Should I choose a smaller or larger diameter cutter?
Choose the diameter based on your exact bolt or clearance hole requirement; smaller sizes are for standard fasteners, while larger sizes are for heavy structural joints.
How does the price vary among the variants?
Price increases with both the diameter of the cutter and the cutting depth, reflecting the larger amount of premium HSS material used.
