Schifler Core Drill HSS Cutter 27x35 mm
This HSS Annular Cutter is engineered for precision hole making on magnetic drill machines, handling various steel types. The 27 mm diameter allows for 35 mm cutting depth with minimal waste. • Weldon shank 19.05 mm for high-torque security • Works on Mild Steel, Stainless Steel, and Alloy Steel • Reduces power consumption during core drilling • Suitable for fabrication and heavy machinery maintenance
Specifications
For: 27x35 mm- SIze
- 27 mm
- Cutting depth
- 35 mm
- Product Name
- HSS Annular Cutter
- Shank Type
- Weldon Shank
- Shank Size
- 19.05 mm (3/4")
- Application Material
- Mild Steel, Stainless Steel, Alloy Steel, Aluminium
- Suitable Machine
- Magnetic Drill Machine
Configurations
Click a row to switch| Variant | Cutting depth | SIze | Shank Size | Shank Type | Price |
|---|---|---|---|---|---|
| 27x35 mm | 35 mm | 27 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,710 |
| 28x35 mm | 35 mm | 28 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,845 |
| 28.5x35 mm | 35 mm | 28.5 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,845 |
| 29x35 mm | 35 mm | 29 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,845 |
| 30x35 mm | 35 mm | 30 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,925 |
| 30.5x35 mm | 35 mm | 30.5 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,925 |
| 31x35 mm | 35 mm | 31 mm | 19.05 mm (3/4") | Weldon Shank | ₹1,925 |
| 31.5x35 mm | 35 mm | 31.5 mm | 19.05 mm (3/4") | Weldon Shank | ₹2,012 |
| 32x35 mm | 35 mm | 32 mm | 19.05 mm (3/4") | Weldon Shank | ₹2,012 |
| 32.5x35 mm | 35 mm | 32.5 mm | 19.05 mm (3/4") | Weldon Shank | ₹2,012 |
| 33x35 mm | 35 mm | 33 mm | 19.05 mm (3/4") | Weldon Shank | ₹2,012 |
| 33.5x35 mm | 35 mm | 33.5 mm | 19.05 mm (3/4") | Weldon Shank | ₹2,118 |
| 34x35 mm | 35 mm | 34 mm | 19.05 mm (3/4") | Weldon Shank | ₹2,118 |
| 35x35 mm | 35 mm | 35 mm | 19.05 mm (3/4") | Weldon Shank | ₹2,118 |
Maintenance and Handling Tips
- Apply appropriate cutting fluid to extend tool life and improve finish
- Store cutters in dry conditions to prevent corrosion on cutting edges
- Inspect shank regularly for wear to ensure proper machine fit
- Avoid mixing different shank sizes to prevent alignment issues
- Follow manufacturer torque guidelines for optimal magnetic drill performance
Key Operational Benefits
- Reduces cycle time compared to twist drills for large diameter holes
- Produces near-net-shape holes minimizing post-processing needs
- Lower power consumption due to efficient chip evacuation design
- Enhances operator safety by reducing vibration and kickback risk
- Cost-effective solution for high-volume production environments
Optimized Cutting Depth Range
- Designed for magnetic drill machines with a cutting depth of 35 mm
- Covers the standard range of 27-35 mm for versatile job requirements
- Ensures full penetration capability for structural steel work
- Consistent depth control improves safety and hole quality
- Compatible with standard annular cutter shank configurations
Versatile Material Compatibility
- Ideal for drilling mild steel with consistent chip removal performance
- Effective on stainless steel grades requiring high-cutting speed tools
- Suitable for alloy steel applications demanding durable cutting edges
- Capable of handling aluminium without excessive material buildup
- Reliable performance across a wide range of industrial metal types
High-Performance HSS Construction
- Manufactured from high-speed steel for superior hardness and heat resistance
- Weldon Shank design ensures secure grip and minimal slippage during operation
- Shank sizes available in 19 mm and 25 mm to fit various magnetic drill machines
- Precision-ground cutting edges maintain sharpness for clean, accurate holes
- Optimized geometry reduces torque requirements and extends tool life
More questions buyers ask
What is an HSS annular cutter?
An HSS (High-Speed Steel) annular cutter is a specialized drill bit used with magnetic drilling machines to cut precise, clean holes in metal, offering faster performance than traditional twist drills.
What is the cutting depth of these Schifler cutters?
These Schifler annular cutters are designed with a standard cutting depth of 35 mm.
Which materials can these cutters drill?
They are suitable for mild steel, stainless steel, alloy steel, and aluminium.
What shank type do these cutters use?
These cutters feature a standard Weldon shank for secure fitment in magnetic drill machines.
Are these cutters suitable for industrial use?
Yes, Schifler HSS annular cutters are engineered for heavy-duty industrial metalworking and fabrication applications.
How do I choose the right size?
Choose the diameter based on your specific hole requirement, ranging from 27 mm to 35 mm in this series.
Do these cutters require coolant?
Yes, using appropriate cutting fluid is recommended to extend tool life and improve the surface finish of the hole.
Are these compatible with all magnetic drills?
They are compatible with most standard magnetic drill machines that accept Weldon shank annular cutters.
What is the benefit of using an annular cutter over a twist drill?
Annular cutters remove only the periphery of the hole, requiring less power, drilling faster, and producing less waste.
How should I store these cutters?
Store them in a dry, clean environment to prevent corrosion on the cutting edges.
Who should choose the 27x35 mm variant?
Ideal for users requiring a 27 mm diameter hole in structural steel or metal plates.
Who should choose the 35x35 mm variant?
Best for applications needing a larger 35 mm diameter hole within the 35 mm depth capacity.
How does the 27 mm cutter compare to the 35 mm cutter?
Both offer the same 35 mm cutting depth and material compatibility, with the primary difference being the hole diameter produced.
Are there differences in price between sizes?
Yes, prices vary slightly based on the diameter size due to material usage and manufacturing precision.
