Schifler ARMATURE for magnetic drilling machine SWC 32 PRO MOTOR
Engineered for precise torque transfer in magnetic drilling equipment, this replacement armature supports reliable impact drilling operations. It operates on a single-phase 220V circuit with an 1100W power rating. • Article Number: 716841501797 • Rated for 1100W 220V single-phase operation • Compatible with standard magnetic drill chucks
Specifications
For: SWC 32 PRO MOTOR- Application
- For Impact Drill
- Phase
- Single Phase
- Diameter
- 35 mm
- Winding Material
- Copper
- Body Material
- COPPER
- Voltage
- 1100W 220V
- Article Number
- 716841501797
Configurations
Click a row to switch| Variant | Voltage | Diameter | Price |
|---|---|---|---|
| SWC 32 PRO MOTOR | 1100W 220V | 35 mm | ₹4,419 |
| SWC 40 PRO MOTOR | 1200W 220V | 35 mm | ₹4,719 |
| SWC 50 MAX-PRO MOTOR | 1350W 220V | 35 mm | ₹5,663 |
| SWC 50 MAX-T MOTOR | 1350W 220V | 35 mm | ₹6,006 |
| SWC 65 MOTOR | 1600W 220V | 35 mm | ₹6,692 |
| SWC 65WT MOTOR | 1600W 220V | 35 mm | ₹7,207 |
| SWC 80 MOTOR | 220V | 35 mm | ₹9,867 |
| SWC 80 WT MOTOR | 220V | 35 mm | ₹14,157 |
| SWC 100 MOTOR | 220V | 35 mm | ₹15,873 |
| SWC 100 WT MOTOR | 220V | 35 mm | ₹15,873 |
| SWC 120 WT MOTOR | 2500W 220V | 35 mm | ₹18,361 |
| SWC 35 H MOTOR | 220V | 35 mm | ₹4,719 |
| SWC 35 AT MOTOR | 1100W 220V | 35 mm | ₹6,178 |
| SWC 35 PD MOTOR | 1150W 220V | 35 mm | ₹4,719 |
| SWC 50 PD MOTOR | 220V | 35 mm | ₹6,692 |
| SWC 50 PDT MOTOR | 220V | 35 mm | ₹7,207 |
Installation Guidelines & Long-Term Care
- Verify electrical phase and voltage ratings before initial installation
- Use insulated tools to prevent short circuits during rotor handling
- Store replacement units in dry environments to avoid copper oxidation
- Inspect commutator segments for debris before mounting into housing
- Schedule periodic cleaning to maintain optimal thermal performance
Optimized Rotor Dynamics & Operational Stability
- Precision-balanced rotor geometry reduces mechanical vibration
- Maintains concentric alignment to prevent bearing wear over time
- Minimizes acoustic noise during high-speed rotational cycles
- Ensures consistent power transmission to drill chucks and cutters
- Reduces downtime by preventing premature motor component failure
Heavy-Duty Copper Winding & Rotor Design
- Constructed with high-purity copper winding for superior conductivity
- Features a robust copper body to withstand high thermal stress
- Single phase copper winding construction minimizes electrical resistance
- Optimized thermal dissipation extends service life in heavy use
- Resists insulation breakdown under continuous high-current operation
Broad Compatibility Across SWC Motor Series
- Directly compatible with standard magnetic drill chuck interfaces
- Designed to integrate seamlessly with the complete SWC motor lineup
- Supports SWC 32 PRO MOTOR and SWC 40 PRO MOTOR variants
- Fits SWC 35 H MOTOR, SWC 35 PD MOTOR, and SWC 35 AT MOTOR
- Works with SWC 50 MAX-PRO MOTOR, SWC 50 MAX-T MOTOR, and SWC 65 MOTOR
- Compatible with SWC 50 PD MOTOR, SWC 65WT MOTOR, and SWC 50 PDT MOTOR
- Supports SWC 80 MOTOR, SWC 80 WT MOTOR, SWC 100 MOTOR, and SWC 100 WT MOTOR
- Fits SWC 120 WT MOTOR and other SWC motor configurations
- Reference Article Number: 716841501797 for precise procurement matching
High-Performance Torque Transfer for Impact Drilling
- Engineered as a direct replacement armature for magnetic drilling machines
- Delivers consistent torque output during demanding impact drilling operations
- Optimized for single-phase 220V circuits – 1100W continuous power rating
- Ensures smooth rotational efficiency across continuous work cycles
- Maintains stable electrical draw under heavy mechanical load
More questions buyers ask
What is an armature in a magnetic drilling machine?
The armature is the rotating part of the electric motor in a magnetic drill, responsible for converting electrical energy into mechanical rotational energy to drive the drill bit.
Why should I choose genuine Schifler spare armatures?
Genuine Schifler armatures are precision-engineered for specific SWC motor series, ensuring perfect fit, optimal torque transfer, and long-term reliability compared to generic alternatives.
How do I know which armature fits my magnetic drill?
Check your drill's motor model (e.g., SWC 32 PRO, SWC 50 MAX-PRO) and match it with the compatible armature variant listed in our product specifications.
What material is used in Schifler armatures?
Schifler armatures feature high-purity copper windings and robust copper bodies designed to withstand high thermal stress and continuous industrial use.
Can I install the armature myself?
While possible, we recommend professional installation to ensure correct alignment, electrical safety, and to maintain warranty coverage.
What are the signs of a failing armature?
Common signs include excessive sparking at the brushes, burning smell, loss of power, unusual noise, or the motor failing to start.
Do these armatures come with a warranty?
Yes, Schifler spare parts are backed by standard manufacturer warranty against manufacturing defects. Please check specific terms at purchase.
Are these armatures compatible with other brands?
These are specifically designed for Schifler SWC series magnetic drilling machines. Compatibility with other brands is not guaranteed.
How can I extend the life of my armature?
Ensure proper ventilation, avoid overloading the motor, keep the commutator clean, and replace carbon brushes before they wear down completely.
What is the voltage rating for these armatures?
Most Schifler armatures are designed for standard single-phase 220V industrial power supply, with power ratings varying by model (1100W to 2500W).
Who should choose the SWC 32 PRO armature?
Choose this if you own the Schifler SWC 32 PRO magnetic drill and require a direct, high-performance replacement for standard drilling tasks.
Who should choose the SWC 120 WT armature?
This is for heavy-duty users of the SWC 120 WT model who need the highest power rating (2500W) for demanding, large-diameter drilling applications.
How does the SWC 50 MAX-PRO compare to the SWC 50 MAX-T armature?
Both are designed for the 50-series motors, but they are tuned for specific performance characteristics of their respective models. Always match the exact motor model number.
Is there a performance difference between the 1100W and 2500W armatures?
Yes, the 2500W armature is built for higher torque and sustained heavy-duty loads, whereas the 1100W is optimized for standard, lighter-duty drilling efficiency.
