Samay-Asia Twin Head Non Motorized Decoiler Machine S-A / TSD-I
This twin head non-motorized decoiler enables continuous material feeding for sheet metal forming and straightening operations. • Handles coil IDs from 350 to 500 mm • Supports outer diameters up to 1000 mm • Each head manages 200 kg loads • Accommodates 200 mm wide light gauge strips
Specifications
For: S-A / TSD-I- Compatibility
- High-speed presses, straighteners, and feeders.
- Expansion
- Manual or Hydraulic
- Cradle Adjustments
- Supports left and right sliding
- Coil Width (MM)
- 200
- Coil ID (MM)
- 350-500
- Coil OD (MM)
- 1000
- Coil Weight (KG) Each Side
- 200
Configurations
Click a row to switch| Variant | Coil ID (MM) | Coil OD (MM) | Coil Weight (KG) Each Side | Price |
|---|---|---|---|---|
| S-A / TSD-I | 350-500 | 1000 | 200 | ₹1,55,520 |
| S-A / TSD-II | 375-525 | 1200 | 500 | ₹2,16,270 |
| S-A / TSD-III | 450-550 | 1200 | 1000 | ₹3,49,920 |
| S-A / TSD-IV | 450-550 | 1200 | 1500 | ₹4,67,775 |
| S-A / TSD-V | 450-550 | 1200 | 3000 | ₹7,95,825 |
Industry Applications
- Sheet metal processing and fabrication lines
- Automotive component manufacturing plants
- Appliance housing production facilities
- Roll forming and punching operations
- General metalworking and stamping industries
Construction Quality
- Built with heavy-duty steel frame for stability
- Precision engineered mandrels for secure gripping
- Low maintenance hydraulic or mechanical systems
- Designed for continuous industrial operation
- Resistant to wear and tear under load
Operational Efficiency
- Reduces material handling time significantly
- Ensures uninterrupted material flow to press lines
- Minimizes machine stoppages during coil changes
- Optimizes throughput for high-volume manufacturing
- Compatible with automated feed systems
Core Capabilities
- Twin head design enables continuous feeding operations
- Supports coil weight of 200 KG each side
- Handles coil width of 200 MM standard
- Accepts Coil ID ranging from 350–500 MM
- Maximum Coil OD capacity reaches 1000 MM
Frequently asked
Can the machine handle varying coil sizes?
Yes, adjustable within specified ID and OD ranges.
Is installation support provided?
Professional setup and calibration assistance available.
What power requirements are needed?
Standard industrial voltage compatible with main line.
More questions buyers ask
What is a twin head decoiler used for?
A twin head decoiler is used in sheet metal processing to hold two coils simultaneously, allowing for continuous feeding to press lines by switching heads, which significantly reduces downtime.
What are the key benefits of Samay-Asia decoilers?
Samay-Asia decoilers offer high precision, heavy-duty construction, reduced material handling time, and seamless integration with automated press feed systems.
Is the Samay-Asia Twin Head Decoiler suitable for high-speed presses?
Yes, it is designed to be compatible with high-speed presses, straighteners, and feeders to ensure uninterrupted material flow.
What is the maximum coil weight capacity?
The capacity varies by model, ranging from 200 KG per side up to 3000 KG per side depending on the specific variant chosen.
Does Samay-Asia provide installation support?
Yes, Samay-Asia offers professional setup and calibration assistance to ensure optimal performance of the decoiler machine.
What materials can this decoiler handle?
It is suitable for various materials including MS, SS, copper strips, aluminum sheets, and GI/CR coils used in stamping and roll forming.
How does the twin head design improve productivity?
The twin head design allows one side to be loaded while the other is feeding, eliminating machine stoppages during coil changes.
Are these machines Made in India?
Yes, Samay-Asia decoilers are proudly manufactured in India, adhering to high-quality industrial standards.
What power supply is required?
The machine is compatible with standard industrial voltage requirements for seamless integration into existing factory setups.
What maintenance is required for these decoilers?
These machines are designed for low maintenance, featuring robust mechanical systems built for continuous industrial operation.
Who should choose the TSD-I model?
The TSD-I is ideal for smaller operations requiring a 200 KG capacity per side and 200 MM width, perfect for light-duty stamping.
Who should choose the TSD-II model?
The TSD-II is best for medium-duty applications needing 500 KG capacity and 300 MM width, offering a balance of power and size.
Who should choose the TSD-III model?
The TSD-III is suited for heavy-duty production lines requiring 1000 KG capacity and 400 MM width for larger coil handling.
Who should choose the TSD-IV model?
The TSD-IV is designed for high-volume industrial use with 1500 KG capacity and 500 MM width, ideal for demanding press lines.
Who should choose the TSD-V model?
The TSD-V is the heavy-duty choice for large-scale manufacturing, supporting 3000 KG capacity and 600 MM width for maximum throughput.
How does TSD-I compare to TSD-V?
TSD-I is a compact 200 KG capacity unit for light tasks, whereas TSD-V is a robust 3000 KG capacity machine built for heavy industrial manufacturing.
Which model is best for 400mm wide coils?
The TSD-III variant is specifically designed to handle coil widths up to 400 MM.
Are all Samay-Asia twin head decoilers motorized?
The standard models are non-motorized, but Samay-Asia offers motorized options depending on the specific industrial requirement.
More like this
Full description
This twin head non-motorized decoiler enables continuous material feeding for sheet metal forming and straightening operations. • Handles coil IDs from 350 to 500 mm • Supports outer diameters up to 1000 mm • Each head manages 200 kg loads • Accommodates 200 mm wide light gauge strips
