Specifications
| Variant | Price | Weight Approximate | Table Size | No. of T Slot and Size | Fixing Hole On Base |
|---|---|---|---|---|---|
| Size 510x380x300 mm | ₹38,000.00 | 60 Kgs | 510x380x300 mm | 3x16 mm | 2 Nos. |
| Select the 510x380x300 mm Pentagon box table for smaller radial drills. At 60 Kgs with 16mm T-slots, it is perfect for workshops handling lighter, compact components. | |||||
| Size 640x460x370 mm | ₹52,000.00 | 90 Kgs | 630x460x370 mm | 3x18 mm | 2 Nos. |
| The 640x460x370 mm Pentagon box table is ideal for medium-duty tasks. Weighing 90 Kgs with 18mm T-slots, it balances a compact footprint with a substantial clamping surface. | |||||
| Size 640x500x480 mm | ₹65,000.00 | 120 Kgs | 630x500x480 mm | 3x18 mm | 2 Nos. |
| Choose the 640x500x480 mm Pentagon box table for standard industrial machining. Weighing 120 Kgs with 18mm T-slots, it offers a versatile clamping area for medium-sized components. | |||||
| Size 800x630x500 mm | ₹88,000.00 | 250 Kgs | 800x630x500 mm | 3x22 mm | 2 Nos. |
| Opt for the 800x630x500 mm Pentagon box table for larger workpieces. With a 250 Kg build and 22mm T-slots, it provides exceptional stability for heavy-duty boring and drilling. | |||||
| Box Table for Radial Drill Machine Size 1000*800*560 mm | ₹1,35,000.00 | 280 Kgs | 1000*800*560 mm | 3x24 mm | 2 Nos. |
| The massive 1000x800x560 mm Pentagon box table is designed for oversized industrial applications. Weighing 280 Kgs with 24mm T-slots, it handles the heaviest machining loads. | |||||
Description
Box Table suitable for Radial Drilling machine models HMT / Batliboi / SAMSON / PENTAGON / WDM / SMTCL / ZJ size (LxWxH) 630x500x480 mm with T slots.
640×500×480 mm box table is a robust and precision-machined accessory widely used with radial drilling machines, boring machines, and milling equipment. Manufactured from high-grade FG-260/FG-300 cast iron, the table ensures superior rigidity, reduced vibration, and enhanced machining accuracy. Its top and side surfaces are machined with standardized T-slots to allow multi-directional clamping and fixture orientation
Features
- Heavy ribbed casting for rigidity
- Precision-ground surfaces and slots
- Multi-face clamping for various orientations
- Designed for heavy drilling & boring loads
- Reduces vibration for better machining accuracy
- Rust-resistant industrial paint finish on non-machined areas
- Suitable for fixture & jig mounting
Advantages
- Enables precise multi-side machining
- Reduces setup change and alignment time
- Handles heavy off-center clamping loads
- Enhances drilling repeatability and output
- Long service life with stable casting
- Ideal for repetitive industrial production setups
Applications
Widely used with:
- Radial Drilling Machines
- Pillar & Column Drilling Machines
- Boring & Milling Machines
- Tool Room Fixtures
- CNC / VMC Work holding (manual setups)
- Inspection & Layout Work
- Fabrication & Workshop Machining
Frequently Asked Questions
Q.What is the use of a box table in a radial drilling machine?
A box table provides a raised, precision-machined surface with T-slots for securely clamping workpieces during drilling, boring, and tapping operations.
Q.Is the Pentagon box table made of cast iron?
Yes, it is constructed from heavy-duty ribbed cast iron to ensure maximum rigidity and vibration dampening during heavy machining.
Q.What are the dimensions of the base model box table?
The base model has dimensions of 640x500x480 mm, providing a substantial working area for medium to large components.
Q.Does this box table come with T-slots?
Yes, it features standardized T-slots on multiple faces, allowing for versatile and secure fixture mounting.
Q.Can this box table be used with other machine brands?
Absolutely. It is suitable for use with various radial drilling machines including HMT, Batliboi, SAMSON, WDM, and SMTCL models.
Q.What is the weight of the 640x500x480 mm box table?
The approximate weight of the 640x500x480 mm box table is 120 Kgs, ensuring stability under load.
Q.Do you provide a GST invoice for this product?
Yes, all purchases come with a valid B2B GST invoice to help you claim input tax credit.
Q.Is there a warranty on the Pentagon box table?
Yes, Pentagon provides a standard manufacturer warranty against casting and machining defects.
Q.Do you offer pan-India delivery for this box table?
Yes, we provide safe and reliable pan-India delivery through our logistics partners.
Q.How is the box table mounted on the radial drill base?
It is securely mounted using the fixing holes provided on its base, typically 2 numbers, ensuring it stays firmly in place.
Q.Are the surfaces of the box table precision-ground?
Yes, the working surfaces and T-slots are precision-ground to ensure high accuracy in job positioning and alignment.
Q.Does it help in reducing vibration during machining?
Yes, the heavy ribbed casting significantly reduces vibration, leading to better machining accuracy and longer tool life.
Q.Who should choose the Size 510x380x300 mm box table?
This compact size is ideal for smaller radial drills and workshops handling lighter, smaller components where space is at a premium.
Q.Who should choose the Size 640x460x370 mm box table?
Choose this variant if you need a medium-sized table that balances footprint and clamping area for standard drilling tasks.
Q.Who should choose the Size 640x500x480 mm box table?
This is the standard choice for general-purpose industrial machining, offering a versatile size and 120 Kg weight for stable operations.
Q.Who should choose the Size 800x630x500 mm box table?
Opt for this larger 250 Kg table when working with heavy, bulky components that require a wider clamping surface.
Q.Who should choose the Size 1000x800x560 mm box table?
This massive 280 Kg table is designed for heavy-duty, large-scale industrial applications and oversized workpieces.
Q.What is the difference between the 640x500x480 mm and 800x630x500 mm box tables?
The 800x630x500 mm table offers a significantly larger working area, heavier build (250 Kgs vs 120 Kgs), and larger T-slots (22mm vs 18mm) for heavier clamping.
Q.How does the weight vary across different box table sizes?
Weight scales with size, starting from 60 Kgs for the smallest 510mm table up to 280 Kgs for the largest 1000mm table, providing proportional stability.
Q.Which box table size is best for heavy-duty boring operations?
The larger sizes, such as the 800x630x500 mm or 1000x800x560 mm, are best for heavy-duty boring as their increased mass dampens vibrations effectively.
Q.Are the T-slot sizes the same across all box table variants?
No, T-slot sizes vary to accommodate different clamping forces. Smaller tables use 16mm or 18mm slots, while larger tables feature 22mm or 24mm slots.
