Pentagon Steady Rest for Cone Pulley Lathe Machine suitable for Medium Duty Lathe 10'' Centre
Designed to stabilize long shafts during turning, threading, and boring operations on medium duty cone pulley lathes. This bed-mounted steady rest delivers consistent radial support and minimizes vibration. • Three-point bearing configuration ensures precise alignment • Compatible with 350–450 mm swing and 250–300 mm bed width • Handles workpieces from 20 to 150 mm diameter • Secured via T-bolt clamp and lock nut mechanism
See it in action
Specifications
For: Medium Duty Lathe 10'' Centre- Product Name
- Lathe Steady Rest
- Product Type
- Fixed Steady Rest
- Machine Compatibility
- Medium Duty Cone Pulley Lathe
- Lathe Type
- Medium Duty Lathe Machines
- Swing Over Bed Compatibility
- 350–450 mm
- Bed Width Compatibility
- 250–300 mm
- Maximum Workpiece Diameter
- 20–150 mm (Model Dependent)
- Support Type
- Three-Point Support
- Number of Bearings
- 3
- Locking Mechanism
- Lock Nut
- Mounting Type
- Bed Mounted
- Clamp Type
- T-Bolt Clamp
- Application
- General purpose turning, threading, boring operations
Configurations
Click a row to switch| Variant | Clamp Type | Bed Width Compatibility | Machine Compatibility | Maximum Workpiece Diameter | Price |
|---|---|---|---|---|---|
| Medium Duty Lathe 10'' Centre | T-Bolt Clamp | 250–300 mm | Medium Duty Cone Pulley Lathe | 20–150 mm (Model Dependent) | ₹8,300 |
| Heavy Duty Lathe 12'' Centre 7'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹11,500 |
| Heavy Duty Lathe 12'' Centre 10'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹8,415 |
| Heavy Duty Lathe 12'' Centre 12'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹9,053 |
| Heavy Duty Lathe 12'' Centre 14'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹12,623 |
| Heavy Duty Lathe 12'' Centre 17'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹20,655 |
| Heavy Duty Lathe 12'' Centre 20'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹23,843 |
| Heavy Duty Lathe 15'' Centre 12'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹9,945 |
| Heavy Duty Lathe 15'' Centre 14'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹12,495 |
| Heavy Duty Lathe 15'' Centre 17'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹21,165 |
| Heavy Duty Lathe 15'' Centre 20'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹25,245 |
| Heavy Duty Lathe 10'' Centre 7'' Hole | T-Bolt Clamp | 300–450 mm | Heavy Duty Cone Pulley Lathe Machine | 50–300 mm (Model Dependent) | ₹7,089 |
| Medium Duty Lathe 8.5'' Centre | T-Bolt Clamp | 250–300 mm | Medium Duty Cone Pulley Lathe Machine | 20–150 mm (Model Dependent) | ₹5,304 |
| Light Duty Lathe 7.5'' Centre | T-Bolt Clamp | 150–250 mm | Light Duty Cone Pulley Lathe Machine | 10-60 mm (Model Dependent) | ₹4,208 |
| Light Duty Lathe 6.5'' Centre | T-Bolt Clamp | 150–250 mm | Light Duty Cone Pulley Lathe Machine | 10-60 mm (Model Dependent) | ₹3,570 |
Durability & Operational Reliability
- Hardened steel contact surfaces resist wear from repeated clamping
- Precision-ground bearing races maintain consistent rotational tolerance
- Sealed bearing design protects against coolant ingress and debris
- Regular lubrication of guide rails extends service life significantly
- Torque-checked lock nuts prevent loosening during heavy cuts
- Routine jaw inspection ensures optimal grip and concentricity
Precision Turning Applications
- Ideal for long shaft turning operations requiring extra support
- Prevents workpiece deflection during precision threading cycles
- Enhances accuracy for deep boring and internal contouring tasks
- Handles workpiece diameters – 20 to 150 mm depending on model selection
- Reduces chatter and improves surface finish on extended parts
- Supports continuous production runs with minimal setup adjustments
Machine Compatibility & Mounting
- Engineered specifically for medium duty cone pulley lathe machines
- Fully compatible with conventional centre lathe configurations
- Supports swing over bed dimensions – 350 to 450 mm for secure mounting
- Bed width compatibility spans – 250 to 300 mm for stable installation
- Bed mounted installation maintains optimal alignment with spindle axis
- T-bolt clamp system ensures vibration-free operation during cutting
Core Design & Support Mechanism
- Fixed steady rest design delivers rigid workpiece stabilization
- Three-point support system ensures uniform radial load distribution
- Three precision bearings minimize friction during high-speed rotation
- Lock nut mechanism secures jaw positions for consistent alignment
- T-bolt clamp enables rapid, tool-free mounting to the lathe bed
- Adjustable jaws accommodate varying workpiece diameters with ease
Frequently asked
How do I verify compatibility before purchasing?
Match your lathe swing over bed (350–450 mm) and bed width (250–300 mm) for secure mounting.
Can this steady rest handle heavy cutting loads?
Yes, the three-point support and lock nut mechanism distribute radial forces for medium duty operations.
How often should the bearings be lubricated?
Apply light machine oil to the bearing races and guide surfaces every 500 operating hours or per schedule.
Is the jaw adjustment reversible for different diameters?
The three adjustable jaws can be repositioned to support workpieces between 20 and 150 mm via the lock nut.
More questions buyers ask
What is a steady rest used for on a lathe?
A steady rest supports long or slender workpieces to prevent deflection and chatter during machining.
How do I choose the right steady rest for my lathe?
Match the steady rest to your lathe's swing over bed and bed width specifications.
Are Pentagon steady rests compatible with all lathes?
They are designed for conventional cone pulley lathe machines; verify your specific bed dimensions before purchase.
What is the difference between a fixed and traveling steady rest?
A fixed steady rest mounts to the lathe bed to support a stationary point, while a traveling steady rest moves with the carriage.
How often should I lubricate the steady rest jaws?
Regular lubrication every 500 operating hours is recommended to maintain precision and reduce wear.
Can these steady rests handle heavy-duty machining?
Yes, we offer heavy-duty models with 4-bearing support designed for rigorous industrial applications.
What material are the contact surfaces made of?
Pentagon steady rests feature hardened steel contact surfaces for maximum durability.
Do you provide warranty on these accessories?
Yes, all Pentagon lathe accessories come with standard manufacturer warranty and service support.
Is installation difficult?
No, the T-bolt clamp system allows for quick and secure mounting to the lathe bed.
What is the maximum diameter these can support?
Our range covers diameters from 10 mm up to 300 mm depending on the specific model.
Who should choose the Medium Duty Lathe 10'' Centre steady rest?
Ideal for workshops performing general-purpose turning, threading, and boring on medium-duty lathes.
Who should choose the Heavy Duty Lathe 12'' Centre 7'' Hole steady rest?
Best for heavy-duty industrial turning and long shaft support requiring robust 4-bearing stability.
Who should choose the Light Duty Lathe 6.5'' Centre steady rest?
Perfect for light-duty lathe machines handling smaller diameter shafts and precision components.
How does the 3-bearing model compare to the 4-bearing model?
The 3-bearing model is optimized for medium-duty precision, while the 4-bearing model provides extra rigidity for heavy-duty rough machining.
Which steady rest is best for long shaft turning?
Heavy-duty models with 4-bearing support are recommended for superior stability during long shaft turning operations.
