Pentagon Semi Automatic Pipe, Tube and Bar Cutting Machine SOHIT-350
The Pentagon SOHIT-350 is a semi-automatic pipe, tube, and bar cutting machine designed for precision industrial fabrication. It delivers high-efficiency cutting with minimal material waste. • Max. Cutting Pipe Diameter: 100 mm • Cutting Accuracy: ±0.1 mm • Max. Clamping Area: 100 × 100 mm • Supports solid bars up to 40 mm diameter
Specifications
For: SOHIT-350- Model
- Sohit-350
- Max. Cutting Pipe Diameter
- 100 mm
- Thickness of Pipe
- 4–5 mm
- Max. Cutting Dia for Solid Bar-Shaft
- 40 mm
- Square Pipe Max Cutting Dia
- 80 × 80 mm
- Rectangle Pipe Cutting Size
- 100 × 80 mm
- Spindle Speed
- Solid Bar: 35/30 (r/min) Pipe: 70/80 (r/min)
- Cutting Accuracy
- ±0.1 mm
- Clamping Method
- Left and Right
- Max. Clamping Area
- 100 × 100 mm
- Working Pressure
- 35–50 Kg/cm²
- Head Motor
- 3 HP / 3 Stages
- Cooling Pump Power
- 0.75 HP
- Applicable Saw Blade
- 300 / 315 / 350 / 370 mm
- Machine Weight
- 650 Kgs
Operational Efficiency Benefits
- Semi-automatic design balances speed and control
- Reduces material waste via precise cuts
- Easy setup for various tube and bar sizes
- Low maintenance requirements for longevity
- Compact footprint fits standard workshop layouts
- Enhances overall production throughput
- Reliable performance in demanding environments
Ideal Industries & Applications
- Structural steel fabrication workshops
- HVAC ducting and pipe fitting manufacturing
- Automotive component production lines
- Furniture and railing construction projects
- General mechanical engineering assemblies
- Metal processing and recycling facilities
- Custom metalwork and prototype development
Robust Power & Cooling System
- Head motor power: 3 HP / 3 Stages
- Dedicated cooling pump: 0.75 HP
- Operating pressure: 35–50 Kg/cm²
- Efficient heat dissipation during continuous use
- Reduces blade wear through proper lubrication
- Stable hydraulic system for smooth operation
- Designed for industrial duty cycles
Precision Engineering & Accuracy
- Achieves cutting accuracy of ±0.1 mm
- Dual spindle speeds for optimal performance
- Solid bar speed: 35/30 r/min
- Pipe speed: 70/80 r/min
- Left and right clamping method ensures stability
- Max clamping area: 100 x 100 mm
- Consistent results for repetitive production runs
Versatile Cutting Capabilities
- Cuts pipes, tubes, and solid bars with high efficiency
- Handles pipe diameters up to 100 mm effectively
- Supports square pipes up to 80 x 80 mm
- Accommodates rectangular pipes up to 100 x 80 mm
- Max solid bar cutting diameter is 40 mm
- Pipe wall thickness range: 4–5 mm
- Compatible with blades from 300 to 370 mm
Standard Accessories
- Sets of Tooling
- Tool Box
- Coolant Pump
- HSS Circular Saw Blade
- Oil Pressure System
More questions buyers ask
What is the Pentagon SOHIT-350 cutting machine?
The SOHIT-350 is a high-performance semi-automatic machine designed for precision cutting of pipes, tubes, and solid bars in industrial applications.
What materials can the SOHIT-350 cut?
It is capable of cutting structural steel pipes, tubes, and solid bars up to 100mm in diameter.
What is the cutting accuracy of this machine?
The machine offers a high cutting accuracy of ±0.1 mm, ensuring precise results for repetitive production runs.
Does it come with a cooling system?
Yes, it includes a dedicated 0.75 HP cooling pump to manage heat and extend blade life during continuous operation.
What is the motor power of the SOHIT-350?
The machine is equipped with a robust 3 HP, 3-stage head motor for reliable industrial performance.
What is the maximum pipe diameter it can handle?
It can handle pipe diameters up to 100 mm.
Is this machine suitable for heavy-duty use?
Yes, it is designed for industrial duty cycles, making it ideal for fabrication workshops and manufacturing lines.
What accessories are included?
Standard accessories include a set of tooling, tool box, coolant pump, HSS circular saw blade, and an oil pressure system.
What is the machine weight?
The SOHIT-350 weighs approximately 650 Kgs.
Does it support square and rectangular pipes?
Yes, it supports square pipes up to 80 x 80 mm and rectangular pipes up to 100 x 80 mm.
Who should choose the Pentagon SOHIT-350?
The SOHIT-350 is the ideal choice for structural steel fabricators, HVAC manufacturers, and automotive workshops requiring high-precision, semi-automatic cutting capabilities.
How does the SOHIT-350 compare to manual cutters?
Compared to manual cutters, the SOHIT-350 offers significantly higher precision, reduced material waste, and faster production throughput due to its semi-automatic hydraulic operation.
