Pentagon High Speed Portable Metal Edge Handheld Electric Chamfering Machine D120
This portable chamfering tool prepares metal edges for welding and structural assembly. It processes non-heat-treated components while maintaining consistent bevel geometry. • 1400W motor operates at 11000 rpm for straight or curved paths • Cutting depth adjusts from 0 to 3 mm at a fixed 45° angle • 4kg chassis reduces operator fatigue during extended field use • 3.0A current draw enables direct connection to standard 220V circuits
Specifications
For: D120- Model
- D-120
- Chamfering Depth
- 0-3 mm
- Power
- 220V,50HZ,1400W
- Current
- 3.0A
- Speed Straight Line / Curved
- 11000 rpm
- Chamfering Angle
- 45°
- Net Weight
- 4kg
Operational Efficiency and Safety
- Low current draw of 3.0A reduces strain on power sources
- Ergonomic handheld design minimizes operator fatigue and strain
- Enables quick setup and immediate start without complex calibration
- Simplifies workflow by combining multiple edge prep steps into one tool
- Enhances workplace safety through controlled, guided cutting action
- Facilitates faster project turnaround times with reduced labor costs
Ideal Applications Across Industries
- Perfect for pipe fitting and flange preparation in oil and gas sectors
- Essential for structural steel fabrication and construction projects
- Suitable for shipbuilding and marine repair edge treatments
- Effective for automotive manufacturing and assembly line tasks
- Used in boiler making and pressure vessel fabrication processes
- Supports general metalworking and maintenance repair operations
Robust Construction for Industrial Durability
- Built with heavy-duty components to withstand demanding industrial environments
- Lightweight yet sturdy frame ensures operator comfort during extended use
- Engineered to handle continuous duty cycles in fabrication shops
- Resistant to wear and tear from frequent contact with metal surfaces
- Provides stable performance even under high-load operating conditions
- Designed for reliable long-term service in harsh workshop settings
Precision Beveling and Edge Preparation
- Achieves precise 45-degree chamfer angles for optimal weld preparation
- Adjustable chamfering depth ranging from 0 to 5 mm for flexible processing
- Capable of handling both straight line and curved surface operations
- Ensures smooth, burr-free edges ready for subsequent welding or finishing
- Reduces manual grinding time by automating the beveling process
- Maintains consistent angle accuracy across long runs of material
High-Speed Portable Chamfering Performance
- Delivers high-speed operation at up to 8500 rpm for efficient material removal
- Equipped with a powerful 1400W motor for consistent cutting performance
- Operates on standard 220V, 50Hz power supply for versatile site usage
- Designed as a handheld electric tool for maximum portability and ease of use
- Ideal for rapid edge preparation on various metal workpieces
- Compact design allows access to tight spaces and complex geometries
More questions buyers ask
What is a portable chamfering machine used for?
A portable chamfering machine is used for creating beveled edges on metal plates, pipes, and structural steel, ensuring smooth finishes and preparing edges for welding.
Can this machine handle curved edges?
Yes, this handheld electric chamfering machine is designed to handle both straight lines and curved edges efficiently.
What is the chamfering capacity of the D120 model?
The D120 model offers a chamfering depth of 0-3 mm with a 45-degree angle.
Is this machine suitable for industrial use?
Yes, it is built for industrial metal edge finishing, deburring, and preparation tasks in workshops and manufacturing units.
What power supply does it require?
It operates on a standard 220V, 50Hz power supply with a 1400W motor.
How much does the machine weigh?
The D120 model is lightweight, weighing approximately 4kg, making it easy to handle for extended periods.
What is the operating speed of the D120?
The D120 operates at a high speed of 11,000 rpm for efficient material removal.
Does it come with a warranty?
Yes, Pentagon provides standard manufacturer warranty support for their industrial tools.
Is GST invoice provided with the purchase?
Yes, all purchases include a valid GST invoice for business accounting purposes.
Do you offer delivery across India?
Yes, we provide reliable pan-India delivery for all industrial machinery and tools.
Who should choose the Pentagon D120?
The D120 is ideal for fabricators and workshop operators who need a lightweight, high-speed tool for precision edge finishing on metal components.
How does the D120 compare to larger stationary chamfering machines?
The D120 offers superior portability and flexibility for on-site work, whereas stationary machines are better suited for high-volume, repetitive production runs on fixed workpieces.
