Toolvisor Magnetic Drill Machine TV.40
Engineered for core drilling and tapping on ferrous steel in vertical, horizontal, or overhead positions. Optimized for mobility, this compact model features a 250 mm rail length and 290 to 430 mm height range for confined workspaces. • 10000 N holding capacity ensures stability during light to medium duty tasks • 1050 W motor handles annular cutters from 12 to 40 mm • 9.5 kg weight and 140 mm stroke facilitate rapid deployment
Specifications
For: TV.40- LENGTH
- 250 mm
- WIDTH
- 110 mm
- HEIGHT
- 290 – 430 mm
- ANNULAR CUTTERS
- 12 – 40 mm
- THREADING
- M3 - M24
- STROKE
- 140 mm
- spindle
- M24 with integrated tool cooling and lubrication
- MOTOR POWER
- 1050 W
- SPEED
- 400 rpm
- SPINDLE WELDON
- 19.05 mm / ¾”
- POWER SOURCE
- 220 – 240V AC 50 ~ 60 HZ
- gearbox
- Two-speed
- magnet
- Strong dual coil CNC machined magnet
- Spindle
- 19mm (3/4") Weldon
- TWIST DRILLS
- 6-13 mm (Weldon Drill)
- COUNTERSINKING
- 10 – 40 mm
- MAGNETIC FORCE
- 10000 N
- TOTAL POWER
- 1100 W
- SPEED (no load)
- 750 rpm
- WEIGHT
- 9.5 kg
Configurations
Click a row to switch| Variant | ANNULAR CUTTERS | HEIGHT | LENGTH | MAGNETIC FORCE | Price |
|---|---|---|---|---|---|
| TV.60T | 12 – 60 mm | 440 – 620 mm | 300 mm | 10000 N | ₹36,380 |
| TV.40 | 12 – 40 mm | 290 – 430 mm | 250 mm | 10000 N | ₹22,950 |
Setup, Care & Handling Guidelines
- Verify ferrous surface cleanliness before engaging the magnetic base
- Apply recommended cutting oil to extend annular cutter lifespan
- Inspect power cord and plug integrity before each operational shift
- Store unit in a dry environment to protect internal motor components
- Follow manufacturer torque guidelines when mounting accessories
- Complies with standard industrial safety protocols for portable machinery
Industrial Applications & Use Cases
- Heavy structural steel fabrication and erection projects
- On-site pipeline welding preparation and flange drilling
- Shipbuilding and offshore platform maintenance operations
- Bridge construction and rail infrastructure maintenance
- Plant shutdowns requiring rapid setup and precision tapping
- Metal fabrication shops handling thick plate and beam drilling
Spindle Design & Power Integration
- M24 spindle with integrated tool cooling and lubrication system
- MT3 spindle taper ensures precise tool alignment and runout control
- Weldon drive size of 19.05 mm / ¾ for secure cutter retention
- Operates on standard 220 – 240 V AC power at 50 – 60 Hz
- Two-speed gear configuration optimizes feed rates for different materials
- Compact footprint reduces workspace clutter during active machining
Secure Mounting & Positioning
- Equipped with a strong dual coil CNC machined magnet base
- Delivers holding capacity up to 10000 N for safe overhead work
- Height adjustment spans 290 mm to 620 mm for structural access
- Column or rail length options from 250 mm to 300 mm
- Unit weight ranges from 9.5 kg to 21 kg for easy site transport
- Designed for stable drilling in vertical, horizontal, and overhead positions
Core Capabilities & Performance
- Motor power options range from 1050 W to 1600 W for consistent torque
- Accepts annular cutters from 12 mm to 60 mm diameter across variants
- Supports twist drills from 6 mm to 32 mm for versatile hole making
- Enables countersinking operations from 10 mm to 60 mm
- Covers threading range from M3 to M24 with precision feed control
- Features a two-speed gearbox for speeds between 320 and 600 rpm
- Stroke length options include 140 mm and 175 mm for deep penetration
Frequently asked
Can this magnetic drill operate on vertical and overhead surfaces?
Yes, the dual coil magnet provides secure holding force for all positions.
What power supply is required for operation?
The unit runs on standard 220 – 240 V AC at 50 – 60 Hz.
How do I ensure accurate hole placement during setup?
Use a center punch or pilot drill to mark the exact drilling point.
Is the machine suitable for threading large diameter bolts?
Yes, the integrated gearbox supports threading from M3 up to M24.
More questions buyers ask
What is a magnetic drill machine?
A magnetic drill machine is a portable drilling machine with an electromagnetic base that adheres to a ferrous surface, allowing for precise drilling in various orientations.
What are the key features of the PENTAGON TV.60?
The PENTAGON TV.60 features a 1600W motor, a magnetic force of 10000 N, and a variable speed of 320/600 rpm, making it suitable for a wide range of drilling applications.
What is the warranty on the PENTAGON TV.60?
The PENTAGON TV.60 comes with a 1-year manufacturer warranty against manufacturing defects.
Is the PENTAGON TV.60 suitable for tapping?
Yes, the PENTAGON TV.60 is also capable of tapping threads from M3 to M24.
What is the power requirement for this machine?
The machine operates on a standard 220-240V AC, 50-60Hz power supply.
Can I get a GST invoice for my purchase?
Yes, we provide a GST invoice for all purchases.
Do you offer pan-India delivery?
Yes, we deliver the PENTAGON TV.60 across India.
What is the maximum drilling capacity?
The TV.60 can handle annular cutters up to 60mm and twist drills up to 13mm.
How much does the machine weigh?
The machine weighs 21 kg, making it portable for job site use.
What is the spindle type?
The spindle is an MT3 type with a 19.05mm (3/4''') Weldon shank.
Who should choose the PENTAGON TV.60 Magnetic Drill Machine?
The PENTAGON TV.60 is ideal for fabrication shops, construction sites, and maintenance crews who require a powerful and portable drilling solution for heavy-duty tasks on ferrous metals.
How does the TV.60 compare to other models?
The TV.60 offers a higher magnetic force and a more powerful motor compared to smaller models, making it suitable for larger diameter drilling and tapping operations.
