Specifications
| Variant | Price | Pressure in Tons | Gross Weight | Size | Packing dimension | Formers in N.B. |
|---|---|---|---|---|---|---|
| 3/8" to 1" | ₹13,400.00 | 10 | 26 – 30 kg | 3/8" to 1" | 670 × 190 × 420 mm | 3/8", 1/2", 3/4" & 1" |
| Compact 10-Ton manual bender for small diameter pipes (3/8"-1"). Ideal for electricians, plumbers, and light fabrication work requiring portability. | ||||||
| 1/2" to 2" | ₹29,610.00 | 15 | 45 – 50 kg | 1/2" to 2" | 730 × 320 × 200 mm | 1/2", 3/4", 1", 1-1/4", 1-1/2" & 2" |
| Standard 15-Ton hydraulic bender covering the most common 1/2" to 2" range. Perfect for general construction, plumbing, and site fabrication. | ||||||
| 1/2" to 3" | ₹42,300.00 | 20 | 100-120 kg | 1/2" – 3" | 940 × 400 × 210 mm | 1/2", 3/4", 1", 1/4",1-1/2", 2", 2-1/2" & 3" |
| Heavy-duty 20-Ton machine extending capacity to 3 inches. Suitable for industrial piping and larger commercial installations. | ||||||
| 1" to 4" | ₹69,750.00 | 20 | 150-165 kg | 1" to 4" | 1180 × 460 × 250 mm | 1", 1-1/4", 1-1/2", 2"2-1/2", 3" & 4" |
| Specialized 20-Ton bender for large pipes starting from 1 inch up to 4 inches. Best for heavy industrial lines where small pipes are not needed. | ||||||
| 1/2" to 4" | ₹72,675.00 | 20 | 135-165 kg | 1/2"–4" | 1180 × 460 × 330 mm | 1/2", 3/4", 1"1-1/4", 1-1/2", 2"2-1/2", 3" & 4" |
| Versatile 20-Ton all-rounder covering the full 1/2" to 4" spectrum. The ultimate choice for contractors handling diverse pipe sizes. | ||||||
| 2" to 6" | ₹98,775.00 | 30 | 350 – 400 kg | 2" to 6" | 1200 × 600 × 300 mm | 2", 2-1/2", 3"4", 5" & 6" |
| Massive 30-Ton industrial bender for large 2" to 6" pipes. Designed for heavy engineering, oil & gas, and infrastructure projects. | ||||||
Maintenance & Longevity
Cost-Effective Manual Operation
Versatile Applications & Portability
Robust Construction & Stability
Operational Capabilities & Precision
Frequently Asked Questions
Q.What types of pipes can the Pentagon Hand Hydraulic Pipe Bender bend?
This machine is designed specifically for bending 'C' class MS (Mild Steel) and GI (Galvanized Iron) pipes, commonly used in water, gas, and steam applications.
Q.Does this pipe bender require electricity?
No, this is a purely manual hydraulic machine. It operates using a hand-pump lever to generate hydraulic pressure, making it ideal for sites without power.
Q.What is the maximum bending angle achievable?
The machine can typically achieve bends up to 90 degrees in a single setup. For other angles, careful manual control is required.
Q.Does the machine come with bending formers (dies)?
Yes, each model comes with a specific set of cast iron formers (dies) corresponding to the pipe sizes it supports (e.g., 1/2", 3/4", 1", etc.).
Q.What hydraulic oil should be used in this bender?
We recommend using standard hydraulic oil like Enklo 68 or Servo 68 for smooth operation and longevity of the hydraulic cylinder.
Q.Is the machine portable?
Yes, the smaller models (up to 2 inches) are relatively portable. Larger models (3 inch, 4 inch, 6 inch) are heavy-duty and best used in a fixed workshop setting or moved with equipment.
Q.What is the warranty period for this product?
The Pentagon Hand Pipe Bender comes with a 1-year warranty against manufacturing defects. Wear and tear on dies/seals is not covered.
Q.Can I get a GST invoice for my business purchase?
Yes, we provide a fully compliant GST invoice with every purchase, allowing you to claim input tax credit.
Q.Do you deliver this machine across India?
Yes, we offer pan-India delivery via reliable logistics partners to all major industrial hubs and remote locations.
Q.Is the tripod stand included?
Most models feature a stable base or tripod-style design for stability during bending. Please check the specific variant image or specs.
Q.Who should choose the 3/8" to 1" Hand Pipe Bender?
This compact 10-ton model is perfect for plumbers and electricians working with small-diameter conduit and water pipes who need a lightweight, portable tool.
Q.Who is the 1/2" to 2" model best suited for?
The 15-ton 2-inch model is the industry standard for general fabrication and plumbing, covering the most common pipe sizes used in construction.
Q.When should I opt for the 1/2" to 3" model?
Choose this 20-ton model if you work with larger industrial piping but still need the flexibility to bend smaller 1/2" pipes occasionally.
Q.Who needs the 1" to 4" Pipe Bender?
This heavy-duty 20-ton unit is designed for heavy industrial piping, fire fighting lines, and large infrastructure projects where pipes start from 1 inch.
Q.What is the advantage of the 1/2" to 4" model?
This versatile 20-ton machine offers the widest range, covering everything from small domestic pipes to large industrial mains, ideal for diverse contractors.
Q.Who requires the massive 2" to 6" Pipe Bender?
This 30-ton beast is strictly for heavy engineering and oil & gas sectors requiring bending of very large diameter pipes up to 6 inches.
Q.What is the difference between the 1"-4" and 1/2"-4" models?
The main difference is the range of dies included. The 1/2"-4" model includes smaller formers (1/2", 3/4") making it more versatile, whereas the 1"-4" model focuses only on larger pipes.
Q.How does this manual bender compare to an electric one?
Manual benders are cheaper, portable, and don't need power, but are slower and require physical effort. Electric benders are faster and effortless but much more expensive and heavy.
Q.Can this machine bend square tubes?
No, this specific model is designed only for round 'C' class pipes. Bending square tubes requires different dies and a different machine design.
