Pentagon Machine Tool Control Transformer PMCT-250
The Pentagon Machine tool control transformer provides reliable isolation and voltage conversion for industrial milling equipment. This 250 VA unit ensures stable operation across multiple input voltages including 220V, 380V, 415V, and 440V. Key specifications include: • Three-phase configuration with 50/60 Hz frequency support • Output options: 12V, 24V, or 110V for diverse control circuits • Dry type air-cooled design for maintenance-free performance • Compact dimensions (15x13x15 cm) and lightweight 2.5 kg build
Specifications
For: PMCT-250- Product
- Machine Tool Control Transformer
- Phase
- Three Phase
- Power
- 250 VA
- Frequency
- 50/60 Hz
- Cooling Type
- Dry Type/ Air Cooled
- Input Voltage
- 220V, 380V, 415V, 440V
- Out put Voltage
- 12V, 24V, 110V
- Package size
- 15X13X15 cm
- Single gross weight
- 2.500 kg
Ideal for Machine Tool Applications
- Perfectly suited for milling machines, lathes, and grinding equipment
- Powers control panels, relays, contactors, and indicator lights
- Ensures precise voltage regulation for accurate machine operation
- Extends lifespan of downstream control devices through clean power
Enhanced Safety and Reliability
- Isolates control circuits from main power lines for operator safety
- Protects sensitive electronic components from voltage spikes and noise
- Reduces risk of short circuits in harsh industrial environments
- Maintains consistent performance under varying load conditions
Compact and Efficient Construction
- Air-cooled design ensures quiet operation without auxiliary fans
- Compact package size of 15x13x15 cm fits tight machine enclosures
- Lightweight at 2.5 kg gross weight for easy installation and handling
- Dry-type insulation offers superior safety and lower maintenance needs
Robust Three-Phase Design
- Engineered for stable three-phase power distribution in heavy machinery
- Rated at 250 VA for reliable control transformer performance
- Operates efficiently on both 50 Hz and 60 Hz frequency standards
- Dry type construction eliminates fire hazards associated with oil cooling
Versatile Voltage Conversion
- Supports multiple input voltages: 220V, 380V, 415V, and 440V
- Provides flexible output options including 12V, 24V, and 110V
- Ideal for adapting power sources to specific control circuit requirements
- Ensures compatibility with diverse industrial electrical infrastructures
More questions buyers ask
What is a machine tool control transformer?
A control transformer is an electrical device used to step down voltage to a safe level for operating control circuits, relays, and contactors in industrial machinery.
Why use a Pentagon control transformer?
Pentagon transformers offer robust 3-phase design, dry-type cooling, and versatile voltage conversion, ensuring reliable and safe operation for industrial control panels.
What are the common applications of this transformer?
It is ideal for milling machines, lathes, grinding equipment, and CNC control panels, providing stable power to sensitive electronic components.
Does this transformer support multiple input voltages?
Yes, it supports 220V, 380V, 415V, and 440V inputs, making it highly versatile for different industrial electrical infrastructures.
What is the power rating of this model?
This specific model is rated at 250 VA, suitable for standard machine tool control requirements.
Is this transformer air-cooled?
Yes, it features a dry-type, air-cooled design that ensures quiet operation without the need for auxiliary fans.
What safety features does it provide?
It isolates control circuits from main power lines, protecting sensitive components from voltage spikes and noise while enhancing operator safety.
Can it be used in harsh industrial environments?
Yes, its robust construction and dry-type insulation are designed to withstand varying load conditions and typical industrial environments.
What are the dimensions of the unit?
The compact package size is 15x13x15 cm, making it easy to fit into tight machine enclosures.
What is the weight of the transformer?
The unit has a gross weight of 2.5 kg, ensuring easy installation and handling.
Who should choose the PMCT-250 variant?
The PMCT-250 is ideal for workshops and machine builders requiring a reliable, compact 250 VA control transformer for standard 3-phase machinery control panels.
How does this compare to standard transformers?
Unlike standard transformers, this Pentagon model is specifically engineered for machine tool environments, featuring high-frequency compatibility and compact panel-mount dimensions.
