Specifications
| Variant | Price | Tank Capacity | Model No. | Free Air Delivery (FAD) | Motor Power | Piston Displacement |
|---|---|---|---|---|---|---|
| 3 HP (PT-30T) | ₹38,400.00 | 150 Liter | PT-30T | 250 – 300 LPM | 3 HP | 8 – 10 CFM |
| The 3 HP (PT-30T) Two Stage Air Compressor delivers 250-300 LPM FAD with a 150L tank. Ideal for small workshops and garages requiring reliable 10.5 Bar pressure. | ||||||
| 5 HP (PT-50T) | ₹57,000.00 | 200 Liter | PT-50T | 400 – 450 LPM | 5 HP | 14 – 16 CFM |
| The 5 HP (PT-50T) model offers 400-450 LPM FAD and a 200L tank. Perfect for medium-scale pneumatic applications and automotive workshops. | ||||||
| 7.5 HP (PT-75T) | ₹72,000.00 | 225 Liter | PT-75T | 600 – 700 LPM | 7.5 HP | 21 – 25 CFM |
| Featuring a 225L tank and 600-700 LPM FAD, the 7.5 HP (PT-75T) compressor is designed for growing industrial setups needing consistent air supply. | ||||||
| 10 HP (PT-100T) | ₹76,800.00 | 300 Liter | PT-100T | 700 – 850 LPM | 10 HP | 35-36 CFM |
| The 10 HP (PT-100T) variant provides 700-850 LPM FAD and a 300L tank. A great choice for heavy-duty pneumatic tools and continuous operations. | ||||||
| 10 HP (PT-150T) | ₹82,600.00 | 300 Liter | PT-150T | 850 – 900 LPM | 10 HP | 42-44 CFM |
| With an upgraded 850-900 LPM FAD and a 300L tank, the 10 HP (PT-150T) compressor ensures faster recovery times for demanding industrial tasks. | ||||||
| 12.5 HP (PT-150T) | ₹85,200.00 | 300 Liter | PT-150T | 850 - 900 LPM | 12.5 HP | 48-49 CFM |
| The 12.5 HP (PT-150T) model delivers up to 900 LPM FAD with a 300L tank. Ideal for high-demand workshops requiring stable 10.5 Bar pressure. | ||||||
| 15 HP (PT-150T) | ₹92,800.00 | 300 Liter | PT-150T | 900-1000 LPM | 15 HP | 54-55 CFM |
| Offering 900-1000 LPM FAD and a 300L tank, the 15 HP (PT-150T) compressor is built for large-scale operations and heavy pneumatic machinery. | ||||||
| 15 HP (PT-200T) | ₹1,12,000.00 | 500 Liter | PT-200T | 1000 – 1200 LPM | 15 HP | 66-68 CFM |
| The 15 HP (PT-200T) variant features a massive 500L tank and 1000-1200 LPM FAD. Best suited for heavy industrial applications with high air consumption. | ||||||
| 20 HP (PT-200T) | ₹1,18,000.00 | 500 Liter | PT-200T | 1200 – 1400 LPM | 20 HP | 80-82 CFM |
| The top-tier 20 HP (PT-200T) compressor delivers a maximum 1200-1400 LPM FAD and a 500L tank. The ultimate solution for continuous, heavy-duty industrial use. | ||||||
Advanced Two-Stage Compression Design
• Two-stage reciprocating mechanism ensures higher air delivery and efficiency • Double cylinder design provides better cooling and stable pressure output • Belt-driven system reduces noise and extends machine life significantly • Oil-lubricated pump minimizes wear for enhanced long-term durability • Air-cooled mechanism maintains optimal temperature during extended operation • Heavy-duty tank construction stores sufficient compressed air for continuous use • Automatic pressure switch controls cut-off for safe and reliable operation • Typical configurations deliver 250–300 LPM free air delivery for consistent performance • High-power motor options like 3 HP suit continuous industrial operations • Max working pressure reaches 10.5 Bar for moderate pressure requirements • Typical tank capacity of 150 Liter ensures sufficient air storage
Operational Efficiency and Performance
• Dual cylinder design delivers more air, reducing overall operation time • Faster tank filling improves work efficiency and reduces downtime • Stable pressure ensures smooth tool performance across various applications • Optimized design reduces power consumption for energy-efficient operation • Low vibration and stable running enhance machine life and operator comfort • Simple mechanism allows easy servicing and fewer unexpected breakdowns • Cost-effective solution balancing high performance with investment needs • Designed for regular industrial and workshop use with reliable continuous operation
Maintenance and Serviceability
• Easy maintenance design features simple structure for quick servicing • Oil-lubricated pump reduces wear and enhances durability over time • Air-cooled mechanism maintains optimal temperature during long hours • Low maintenance cost structure minimizes total cost of ownership • Robust construction supports heavy-duty industrial and workshop operations • Standard accessories included for immediate setup and functionality
Comprehensive Safety and Control Features
• Integrated pressure gauge and safety valve monitor system status • Automatic pressure cut-off switch prevents over-pressurization risks • Drain valve and cock allow easy removal of accumulated moisture • Belt guard protects operators from moving mechanical parts • Receiver safety valve ensures tank integrity under high pressure • Delivery valve facilitates controlled air output to connected tools • Slide rails for motor ensure proper alignment and tensioning • Motor pulley and V-belt system provide smooth power transmission
Versatile Industrial Applications
• Automobile workshops for operating impact wrenches and air guns • Spray painting booths for furniture polishing and automotive painting tasks • Pneumatic tool operation suitable for drills, grinders, and nail guns • Woodworking units powering cutting, sanding, and finishing tools • Small manufacturing industries supporting production lines requiring air • Fabrication and engineering workshops running tools for metalworking • Service stations for tyre inflation and general maintenance work • Cleaning applications using air blowing for dust removal and machine cleaning
Frequently Asked Questions
Q: What is the typical pressure range for this compressor? A: Designed for moderate pressure requirements up to around 10.5 Bar. Q: Is this compressor suitable for continuous industrial use? A: Yes, the heavy-duty construction supports regular industrial and workshop use. Q: What safety features are included with the unit? A: Includes safety valve, pressure gauge, drain valve, and pressure cut-off switch.
Frequently Asked Questions
Q.What is the maximum working pressure of the Parth Tech Two Stage Air Compressor?
All models in this series feature a maximum working pressure of 10.5 Bar, ensuring consistent performance for industrial applications.
Q.What are the available motor power options for this compressor?
The compressor is available in multiple motor power options ranging from 3 HP up to 20 HP to suit different operational needs.
Q.What is the tank capacity range for this series?
Tank capacities vary by model, starting from 150 Liters for the 3 HP variant and going up to 500 Liters for the 15 HP and 20 HP models.
Q.What type of drive mechanism does this compressor use?
It uses a highly efficient belt-driven mechanism that reduces noise and extends the overall lifespan of the machine.
Q.Is this an oil-lubricated or oil-free compressor?
This is an oil-lubricated compressor, designed to minimize wear and tear on internal components and enhance durability over time.
Q.What safety features are included in this compressor?
It comes equipped with a safety valve, pressure gauge, drain valve, and an automatic pressure cut-off switch to prevent over-pressurization.
Q.What is the Free Air Delivery (FAD) range?
The Free Air Delivery (FAD) ranges from 250 LPM in the base 3 HP model up to 1400 LPM in the top-tier 20 HP model.
Q.What applications is this two-stage compressor suitable for?
It is ideal for pneumatic tools, spray painting, garage operations, and heavy-duty industrial workshops requiring stable air pressure.
Q.Does the compressor come with an automatic pressure cut-off?
Yes, it features an automatic pressure switch that safely cuts off the motor when the maximum pressure is reached.
Q.How many cylinders does this compressor have?
It features a double cylinder (double piston) design, which provides better cooling and a more stable pressure output.
Q.What is the cooling mechanism used?
The compressor utilizes an air-cooled mechanism to maintain optimal operating temperatures during long hours of use.
Q.Does the price include a GST invoice?
Yes, all purchases come with a valid GST invoice, allowing B2B buyers to claim input tax credit.
Q.Who should choose the 3 HP (PT-30T) variant?
The 3 HP variant is ideal for small workshops and garages needing 250-300 LPM FAD and a 150L tank for standard pneumatic tasks.
Q.Who should choose the 5 HP (PT-50T) variant?
The 5 HP model is best for medium-scale automotive workshops requiring 400-450 LPM FAD and a 200L tank.
Q.Who should choose the 7.5 HP (PT-75T) variant?
This variant is suitable for growing industrial setups that need 600-700 LPM FAD and a 225L tank to run multiple tools simultaneously.
Q.Who should choose the 10 HP (PT-100T) variant?
The 10 HP (PT-100T) is a great choice for heavy-duty pneumatic tools requiring 700-850 LPM FAD and a 300L tank.
Q.Who should choose the 10 HP (PT-150T) variant?
Ideal for continuous operations, this model offers a higher 850-900 LPM FAD with a 300L tank for faster recovery times.
Q.Who should choose the 12.5 HP (PT-150T) variant?
Perfect for demanding industrial applications requiring up to 900 LPM FAD and a 300L tank for stable 10.5 Bar pressure.
Q.Who should choose the 15 HP (PT-150T) variant?
The 15 HP (PT-150T) is best for large-scale workshops needing 900-1000 LPM FAD and a 300L tank.
Q.Who should choose the 15 HP (PT-200T) variant?
Suitable for heavy industrial use, this variant provides 1000-1200 LPM FAD and a massive 500L tank for high air consumption.
Q.Who should choose the 20 HP (PT-200T) variant?
The 20 HP model is the ultimate choice for maximum air demand, offering 1200-1400 LPM FAD and a 500L tank for continuous heavy-duty use.
Q.What is the difference between the 10 HP PT-100T and PT-150T models?
The PT-150T offers a higher FAD of 850-900 LPM compared to the PT-100T's 700-850 LPM, though both feature a 300L tank.
Q.How does the 15 HP PT-150T compare to the 15 HP PT-200T?
The PT-200T provides a higher FAD of 1000-1200 LPM and a larger 500L tank, whereas the PT-150T offers 900-1000 LPM with a 300L tank.
Q.Should I choose the 5 HP or 7.5 HP model for my workshop?
Choose the 5 HP for standard pneumatic tasks (400-450 LPM), and the 7.5 HP if you run multiple tools simultaneously and need higher airflow (600-700 LPM).
Q.What is the difference in tank capacity across the range?
Tank capacities start at 150L for the 3HP model, increase to 200L-300L for mid-range models, and max out at 500L for the 15HP and 20HP PT-200T models.
