Pentagon C03738 Milling Machine Table Lock Handle | Buy Online
Secure your milling machine worktable with this precision locking bolt assembly. Designed for vertical RAM turret milling machines, it ensures stability during heavy cutting operations. • Hardened alloy steel construction for durability • M12 thread type compatible with standard table slots • Includes ergonomic handle for quick engagement
Specifications
For: Milling Machine Worktable Locking Bolt with Handle Model C03738- Product Name
- Table Lock Handle
- Length of Stud
- 26 mm
- Model
- C03738
- Dimensions
- 100x100x50 mm
- Material
- Alloy Steel / Hardened Steel
- Weight
- 0.4 Kgs
- Thread Type
- M12 Inch / MM
- Bolt Length
- 45 mm
Description
The Milling Machine Workbench Table Lock Handle Bolt is a vital component used to securely lock the milling table in position during cutting, drilling, or slotting. Made from high-strength alloy steel, this locking bolt provides stable clamping action and prevents unwanted table movement, ensuring precision in machining tasks.
The ergonomic handle design enables smooth tightening and quick release, while the precision-ground threads ensure long-lasting performance. Suitable for conventional milling machines, turret mills, and universal vertical/horizontal milling machines, this bolt serves as an ideal replacement for worn-out or damaged table lock systems.
Features:
- High-strength alloy steel construction
- Ergonomic handle for easy tightening and loosening
- Precision-cut threads for smooth operation
- Corrosion-resistant surface treatment
- Provides firm table locking for improved accuracy
- Compatible with most vertical and horizontal milling machines
Applications:
- Milling machine X-axis table locking
- Y-axis saddle or cross-slide locking
- Z axis Knee Locking
- Ram Locking
- Machine maintenance and refurbishment
- OEM milling machine assembly
- Replacement for damaged or worn table lock bolts
Advantages:
- Ensures stable worktable positioning during machining
- Reduces table drift and vibration
- Long service life with minimal maintenance
- Enhances operator control and cutting precision
More questions buyers ask
What is the Pentagon C03738 Table Lock Handle used for?
It is used to securely lock the milling table in position during cutting, drilling, or slotting operations on vertical RAM turret milling machines.
What material is the locking bolt made of?
The locking bolt is constructed from high-strength hardened alloy steel for maximum durability and stable clamping action.
What is the thread type of this locking bolt?
It features an M12 thread type, which is compatible with standard table slots on most milling machines.
Is it compatible with all vertical turret milling machines?
It is compatible with most standard vertical and horizontal milling machines that accept M12 threaded locking bolts.
What is the length of the stud?
The stud length of the Pentagon C03738 locking bolt is 26 mm.
How much does the locking bolt weigh?
The complete locking bolt assembly weighs approximately 0.4 Kgs.
Does it come with an ergonomic handle?
Yes, it includes an ergonomic handle designed for quick and easy tightening and loosening.
What are the dimensions of the locking bolt assembly?
The overall dimensions of the assembly are 100x100x50 mm.
Can it be used for X, Y, and Z axis locking?
Yes, it can be used for X-axis table locking, Y-axis saddle or cross-slide locking, Z-axis knee locking, and Ram locking.
Does it prevent table drift during heavy cutting?
Absolutely, it provides firm table locking that prevents unwanted table movement, reducing drift and vibration for improved accuracy.
Who should choose the Pentagon C03738 Table Lock Handle?
Machinists and workshop operators looking for a durable, M12 threaded replacement or upgrade for their vertical RAM turret milling machine's table lock.
How does the C03738 model compare to other table lock handles?
The C03738 stands out with its precision-cut M12 threads, hardened alloy steel build, and ergonomic handle, offering superior clamping force and ease of use.
What makes the M12 thread type suitable for standard table slots?
M12 is a standard metric thread size widely used in industrial machinery, ensuring a perfect fit and secure engagement in standard milling machine T-slots.
Why choose alloy steel over standard steel for locking bolts?
Alloy steel provides higher tensile strength and resistance to wear and corrosion, ensuring a longer service life and reliable performance under heavy machining loads.
