Heavy Duty Planer Type V-Belt Lathe Machine KBHL-10'16''18''90
This heavy duty planer type V belt lathe machine delivers precise turning and facing operations for medium length workpieces. It features a 10 foot bed, 18 inch width, and 16 inch centre height for stable machining. • Admits up to 1778 mm between centres • 90 mm spindle bore for standard bar stock • 3 HP motor with 30-400 RPM spindle speed • 2100 kg frame for vibration control
See it in action
Specifications
For: KBHL-10'16''18''90- Model No.
- KBHL-10'16''18''90
- Length of Bed
- 10'
- Width of Bed
- 18"
- Centre Height
- 16"
- Spindle Bore
- 90 MM
- Admit Between Centre
- 1778 MM
- Swing Bed Diameter
- 787 MM
- Spindle Speed
- 30-400 RPM
- H.P Recommended
- 3 H.P
- Weight
- 2100 Kg
Configurations
Click a row to switch| Variant | Model No. | Spindle Bore | Length of Bed | Centre Height | Price |
|---|---|---|---|---|---|
| KBHL-10'16''18''90 | KBHL-10'16''18''90 | 90 MM | 10' | 16" | ₹3,78,000 |
| KBHL-12'16''18''90 | KBHL-12'16''18''90 | 90 MM | 12' | 16" | ₹4,40,000 |
| KBHL-12'18''20''105 | KBHL-12'18''20''105 | 105 MM | 12' | 18" | ₹4,84,000 |
| KBHL-12'20''22''105 | KBHL-12'20''22''105 | 105 MM | 12' | 20" | ₹6,60,000 |
| KBHL-16'20''22''105 | KBHL-16'20''22''105 | 105 MM | 16' | 20" | ₹7,70,000 |
| KBHL-16'22''24''105 | KBHL-16'22''24''105 | 105 MM | 16' | 22" | ₹8,25,000 |
| KBHL-20'22''24''105 | KBHL-20'22''24''105 | 105 MM | 20' | 22" | ₹9,90,000 |
Optional Accessories
- Four jaw independent chuck
- True chuck
- Electrical motor and switch
- Tool kit
Standard Accessories
- Steady rest
- Follow rest
- Motor plate
- Chuck plate
- Back gears
More questions buyers ask
What is a Planer Type V-Belt Lathe Machine?
It is a heavy-duty industrial lathe designed for large-scale metalworking, offering high torque and stability for heavy-duty turning operations.
What are the key specifications of the Kailash Lathe Machine?
Key specs include a swing bed diameter up to 1092mm, spindle bore up to 105mm, and bed lengths ranging from 10 to 20 feet.
What industries use these lathe machines?
These machines are widely used in heavy engineering, automotive manufacturing, railway workshops, and large-scale fabrication units.
What is the spindle speed range?
The standard spindle speed range for these models is 30-400 RPM, suitable for various turning and finishing tasks.
Are these machines suitable for heavy-duty work?
Yes, they are specifically engineered as heavy-duty planer type machines to handle large, heavy workpieces with precision.
What accessories are included?
Standard accessories include steady rest, follow rest, motor plate, chuck plate, and back gears. Optional items like chucks and tool kits are available.
What is the power requirement?
Depending on the model, these machines require motors ranging from 3 H.P to 7.5 H.P.
How is the machine driven?
These are V-Belt driven machines, known for their reliability, ease of maintenance, and smooth power transmission.
What is the weight of the machine?
The weight varies by model, ranging from 2100 Kg for the 10-foot model up to 4800 Kg for the 20-foot model.
Does it come with a warranty?
Yes, all Kailash lathe machines come with standard manufacturer warranty coverage. Please contact us for specific terms.
Who should choose the 10-foot model?
Ideal for workshops requiring a robust, entry-level heavy-duty lathe for standard turning tasks.
Who should choose the 20-foot model?
Best for large-scale industrial projects requiring maximum bed length and heavy workpiece capacity.
How do the 12-foot models differ?
They offer varying centre heights and spindle bores, allowing users to choose the right balance of power and capacity for their specific needs.
Is the 10-foot model better than the 20-foot model?
It depends on your project size; the 10-foot is more compact, while the 20-foot provides superior capacity for longer workpieces.
Which model offers the highest capacity?
The 20-foot model (KBHL-20'22''24''105) offers the largest admit between centre and overall heavy-duty capacity.
