Great Yuva MIG welding machine EN Series — : YMIG-500EN
The Great Yuva YMIG-500EN Series is a versatile industrial inverter welding machine supporting MIG, TIG, MMA, and Arc Gouging processes. It features IGBT high frequency technology with adaptive switching power supply for wide voltage range operation. • 100% duty cycle per 10 minutes ensures continuous performance • Class H insulation and IP23 protection for industrial durability • VRD 1.5V safety standard with Lift TIG function • Anti-stick electrode function and cooling fan
Specifications
For: : YMIG-500EN- Power supply (V)
- 3P 415V+15%
- Frequency (Hz)
- 50/60
- Rated input current A
- MIG 50/60 TIG 50/60 MMA 50/60 Arc Gouging 50/60
- Output voltage range V
- MIG53-500,TIG5-500,MMA20-500
- No load voltage V
- MIG16.7-39,TIG10.2-30,MMA20.8-40,Arc Gouging24.8-40
- VRD voltage V MIG,TIG,MMA & ARC GOUGING
- 1.5
- Duty cycle
- 100% Per 10minutes
- Power factor
- :>0.93
- Efficiency
- 90
- Type of wire feeder
- Separate
- Wire feeding speed m per min
- 1.5-24
- EMC class
- A
- Insulation class
- H
- Protection class
- IP23
- Weight kg
- 42
- Wire diameter max
- 0.8/1.0/1.2/1.6
- Dimensions LxWxH
- 645X338X620
Configurations
Click a row to switch| Variant | Duty cycle | Insulation class | No load voltage V | Power supply (V) | Price |
|---|---|---|---|---|---|
| : YMIG-500EN | 100% Per 10minutes | H | MIG16.7-39,TIG10.2-30,MMA20.8-40,Arc Gouging24.8-40 | 3P 415V+15% | ₹1,54,350 |
| YMIG-500EN with trolley | 100% Per 10minutes | H | MIG16.7-39,TIG10.2-30,MMA20.8-40,Arc Gouging24.8-40 | 3P 415V+15% | ₹1,81,125 |
| YMIG-500DP EN I | 100% Per 10minutes | H | MIG16.7-39,TIG10.2-30,MMA20.8-40,Arc Gouging24.8-40 | 3P 415V+15% | ₹4,18,950 |
| YMIG-500DP EN II | 100% Per 10minutes | H | MIG16.7-39,TIG10.2-30,MMA20.8-40,Arc Gouging24.8-40 | 3P 415V+15% | ₹6,09,750 |
| GY-YMIG500EN-1424-V6302 | 100% Per 10minutes | H | MIG16.7-39,TIG10.2-30,MMA20.8-40,Arc Gouging24.8-40 | 3P 415V+15% | Quote |
Applications and Industry Use
- Suitable for structural steel work utilizing Arc Gouging capabilities.
- Fits well in environments with standard three-phase power supply access.
- Designed for continuous duty cycles in demanding industrial settings.
- Supports diverse fabrication tasks requiring consistent weld quality.
- Engineered for professional environments demanding high reliability standards.
Construction Quality and Safety Standards
- Protection class IP23 ensures safety against solid objects and water ingress.
- Insulation class H provides high thermal resistance for long component life.
- EMC class A compliance minimizes interference in sensitive industrial environments.
- Dimensions LxWxH measure 645X338X620mm for standard workshop fit.
- Unit weight is 42kg balancing portability with operational stability.
Precision Control and Feed Mechanics
- Wire feeding speed adjusts from 1.5–24 meters per minute accurately.
- Consistent voltage ranges ensure high quality welds across all processes.
- Designed for professional fabrication requiring reliable arc characteristics.
- Ideal for heavy fabrication shops requiring multi-process flexibility.
- Supports maintenance teams needing reliable MIG, TIG, and MMA welding.
Multi-Process Welding Capabilities
- Output voltage range includes MIG53-500, TIG5-500, and MMA20-500 Volts.
- No load voltage covers MIG16.7-39, TIG10.2-30, and MMA20.8-40 Volts.
- VRD voltage is 1.5V for MIG, TIG, MMA, and ARC GOUGING safety.
- Supports wire diameter max of 0.8/1.0/1.2/1.6mm for various joints.
- Separate wire feeder type allows flexible positioning and setup.
Electrical Performance and Stability
- Great Yuva YMIG-500EN Series accepts 3P 415V+15% at 50/60Hz frequency.
- Rated input current remains at 50/60 Amps for MIG, TIG, MMA, and Arc Gouging.
- Efficiency reaches 90% to ensure optimal energy usage during operation.
- Power factor stays greater than 0.93 for consistent electrical performance.
- Duty cycle supports 100% Per 10minutes for heavy industrial tasks.
More questions buyers ask
What is the Great Yuva YMIG-500EN?
The Great Yuva YMIG-500EN is a DC Inverter CC-CV (Constant Current/Constant Voltage) welding machine that supports MIG, MMA, and LIFT TIG welding processes. It is designed for high-precision industrial applications.
What is the duty cycle of the YMIG-500EN?
The YMIG-500EN features a 100% duty cycle, allowing for continuous operation without overheating, making it suitable for demanding industrial environments.
What materials can the Great Yuva YMIG-500EN weld?
This machine is capable of welding a variety of materials, including Carbon Steel, Stainless Steel, and Copper.
What are the input power requirements for the YMIG-500EN?
The YMIG-500EN requires a 3-phase power supply of 415V (+/- 15%) at a frequency of 50/60Hz.
What is the rated input current?
The rated input current is 50/60 Amps for MIG, TIG, MMA, and Arc Gouging processes.
Does the YMIG-500EN have any safety protection features?
Yes, it comes with built-in protection for under-voltage and over-voltage situations, ensuring the longevity and safety of the machine.
Who should choose the YMIG-500EN model?
The YMIG-500EN is ideal for fabrication workshops, heavy industrial manufacturing, and construction sites where a powerful, versatile, and high-duty cycle welding machine is required for various metals.
How does the YMIG-500EN compare to other models in its class?
The YMIG-500EN stands out due to its 100% duty cycle, full digital high-precision control, and multi-process capabilities (MIG/MMA/LIFT TIG), offering a versatile and reliable solution for professional welders.
What is the price of the Great Yuva YMIG-500EN in India?
The price of the Great Yuva YMIG-500EN can vary based on the supplier and included accessories. At Gearo, we offer competitive pricing, GST invoices, and pan-India delivery. Please check the product page for the latest price.
Where can I buy the Great Yuva YMIG-500EN online?
You can purchase the Great Yuva YMIG-500EN directly from the Gearo website. We are an authorized dealer providing genuine products with manufacturer warranties.
