Z Axis Zero Setter AA-703
Secure ferrous workpieces during portable coordinate measuring machine operations with this round magnetic chuck series. Designed for stable holding without clamping marks, it ensures accurate dimensional verification on the shop floor. • Versatile magnetic base for ferrous materials • Compatible with portable CMM inspection probes and arms • Compact design fits tight inspection zones for portable metrology • Series AA-703 offers specific diameter configurations
Specifications
For: AA-703- Series
- AA-703
- Size
- As per requirement
Common Questions & Answers
Q: Can this hold non-ferrous materials? A: No, this magnetic chuck is specifically designed for ferrous materials only. Q: Does it work with all portable CMM brands? A: Yes, it is compatible with most portable CMM inspection probes and arms. Q: How do I ensure accurate zero setting? A: Ensure the workpiece surface is clean and flat for maximum magnetic contact.
Shop Floor Efficiency & Workflow
- Eliminates need for mechanical clamps that leave marks on parts
- Streamlines workflow for engineers performing in-situ measurements
- Provides reliable zero reference point for accurate data collection
- Compatible with standard inspection arms and handheld probes
- Supports efficient production line quality checks without disassembly
Workpiece Safety & Surface Protection
- Constructed with high-grade magnetic materials for consistent holding force
- Surface finish prevents damage to sensitive workpiece geometries
- Robust build withstands frequent shop floor handling and transport
- Maintains magnetic strength over extended periods of regular use
- Designed to minimize wear during repeated clamping cycles
Metrology & Inspection Applications
- Ideal for setup and alignment tasks on portable coordinate measuring machines
- Supports dimensional verification workflows in quality control departments
- Facilitates precise Z-axis referencing for inspection probes
- Reduces setup time during first article inspection processes
- Enhances measurement repeatability across multiple workpiece batches
Design & Series Options
- Compact design fits tight inspection zones for portable metrology
- Series AA-159 offers multiple diameter options to suit different needs
- Available in sizes as per requirement – from standard to custom dimensions
- Round profile allows easy positioning in confined areas
- Supports flexible mounting configurations for diverse setups
Core Functionality & Stability
- Secure ferrous workpieces during portable coordinate measuring machine operations
- Round magnetic chuck series designed for stable holding without clamping marks
- Ensures accurate dimensional verification on the shop floor
- Versatile magnetic base suitable for various ferrous materials
- Compatible with portable CMM inspection probes and arms
More questions buyers ask
What is a Z Axis Zero Setter used for?
A Z Axis Zero Setter is a precision tool used in machining and metrology to accurately determine the zero point of the Z-axis of a CNC machine or a Coordinate Measuring Machine (CMM). This ensures accurate measurements and machining depths.
How does the magnetic base on the Crystal Z Axis Zero Setter work?
The magnetic base allows the setter to be securely attached to any ferrous (iron or steel) surface, such as a machine bed or a large workpiece, without the need for clamps. This provides a stable reference point for measurement.
Is the Crystal Z Axis Zero Setter compatible with all CMM probes?
Yes, it is designed to be compatible with most standard portable CMM inspection probes and arms, making it a versatile tool for various quality control setups.
What is the main advantage of using a Z Axis Zero Setter?
The main advantage is increased accuracy and efficiency. It significantly reduces setup time and eliminates the guesswork involved in setting the Z-axis offset, leading to more precise and consistent machining and inspection results.
What material is the Crystal Z Axis Zero Setter made of?
It is constructed from high-grade materials with a robust build to withstand shop floor environments. The contact surface is designed to be smooth to prevent any damage to sensitive workpiece surfaces.
Can I use this for non-ferrous materials like aluminum?
No, the magnetic base is only effective for holding onto ferrous materials. For non-ferrous materials, a different type of clamping or workholding solution would be required.
Does the Crystal Z Axis Zero Setter require any power source?
No, this is a manual, analog tool and does not require any batteries or external power.
What is the typical accuracy of a Z Axis Zero Setter?
While specifications can vary, high-quality Z Axis Zero Setters offer very high repeatability, often in the range of a few microns (μm), ensuring precise and reliable zero setting.
How do I maintain the Z Axis Zero Setter?
Maintenance is simple. Keep the contact surfaces clean and free of debris. Store it in a safe, dry place to prevent corrosion and protect it from impacts that could affect its accuracy.
Is there a warranty on the Crystal Z Axis Zero Setter in India?
Yes, we offer a standard 1-year warranty against manufacturing defects for all Crystal metrology tools purchased in India.
Who should choose the Crystal AA-703 Z Axis Zero Setter?
The AA-703 model is ideal for workshops and quality control labs that require a reliable and easy-to-use solution for setting Z-axis offsets on portable CMMs and milling machines. Its compact, magnetic design is perfect for quick setups on ferrous workpieces.
What's the difference between a digital and an analog Z Axis Zero Setter?
Analog setters, like the Crystal AA-703, use a dial indicator or a simple mechanical stop, are very robust, and require no batteries. Digital setters feature an LCD screen for a direct numerical readout, which can be easier to read but requires a power source and can be more sensitive to shop floor conditions.
When would I use a Z Axis Zero Setter versus a touch probe?
A Z Axis Zero Setter is a dedicated tool for quickly establishing the Z-height on a flat surface. A touch probe is more versatile and can be used for setting X, Y, and Z axes on complex geometries, but a zero setter is often faster for simple Z-axis referencing.
Is the magnetic base strong enough for vertical or inverted use?
The strength of the magnetic base is designed for secure horizontal placement. While it provides a strong hold, using it in vertical or inverted positions is not recommended as it could lead to a fall and damage the instrument or workpiece.
