Crystal Test Indicator Holder AA-1612
Securely mount dial indicators for accurate measurement and alignment tasks. The AA-161 series offers robust construction for general layout work. • 8 mm diameter stem with 40 mm length accommodates standard indicators • Heavy cast iron base ensures rigid stability during operation • Precision ground beam with fine adjustment screw for exact positioning • Suitable for flat surface marking and inspection tasks
Specifications
For: AA-1612- Brand
- Crystal
- Series
- AA-161
- Size
- 8 mm dia x 40 mm length
Operational Efficiency & Setup
- Streamlines inspection workflows by allowing quick indicator repositioning
- Reduces machine downtime during setup and alignment procedures
- Compatible with standard dial test indicators for immediate integration
- Supports high-volume production environments requiring fast, reliable measurements
Deep-Reach Positioning in Confined Spaces
- Long mounting stem provides extended reach into tight, confined, or deep machine spaces
- 8 mm dia x 40 mm length stem dimensions balance strength with compact clearance
- Enables accurate indicator placement where standard holders cannot fit
- Simplifies access to recessed areas without compromising measurement stability
Rigid Construction & Deflection Control
- Compact, rigid construction reduces indicator deflection during measurement
- Crystal Series AA-161 delivers consistent structural integrity for high-precision tasks
- Model AA-1612 exemplifies the series commitment to durable, vibration-resistant design
- Maintains measurement accuracy under cutting forces and machine vibration
Machine Tool Alignment & Inspection Use Cases
- Mounting dial test indicators onto machine spindles, mill heads, or lathe tool posts
- Reaching deep or hard-to-access internal bores and recesses for alignment checks
- Inspecting component runout, concentricity, and flatness on machine tools
- Setting up workpieces and fixture positioning within CNC machining centers
Precision Articulation & Secure Locking
- Precision test indicator holder designed for secure clamping and flexible positioning
- Articulating joint system allows for easy orientation and fine-tuning of dial test indicators
- Central locking knob freezes the articulated joints firmly in place during measurement
- Maintains zero-backlash stability throughout repeated adjustment cycles
More questions buyers ask
What is a test indicator holder used for?
A test indicator holder is used to securely mount a dial test indicator for precise measurement, alignment, and inspection tasks in machining and manufacturing environments.
What material is the Crystal Test Indicator Holder made of?
The Crystal Test Indicator Holder is made from high-quality, durable materials to ensure stability and longevity in industrial settings. It features a heavy cast iron base for rigidity.
Is the Crystal holder compatible with all dial indicators?
It is designed to be compatible with most standard test indicators with an 8mm stem diameter. Please check your indicator's specifications before purchasing.
What are the dimensions of the holder's arm?
The Crystal AA-1612 model comes with an arm that is 8mm in diameter and 40mm in length.
How do you mount the Crystal Test Indicator Holder?
This model is a non-magnetic stand. It is placed on a flat, stable surface like a granite surface plate or machine bed for accurate measurements.
Does this holder have a magnetic base?
No, the Crystal AA-1612 is a non-magnetic test indicator holder. Crystal offers other models with magnetic bases if required.
What is the price of the Crystal Test Indicator Holder in India?
The price for the Crystal AA-1612 Test Indicator Holder is approximately ₹975, but may vary based on the seller and current promotions.
Can I get a GST invoice for my purchase?
Yes, we provide a GST invoice for all purchases, allowing you to claim input tax credit.
Do you offer pan-India delivery?
Yes, we deliver the Crystal Test Indicator Holder across India to all major cities and industrial areas.
What is the warranty on this product?
The product comes with a standard manufacturer's warranty against manufacturing defects. Please refer to the warranty terms and conditions for more details.
Who should choose the Crystal AA-1612 Test Indicator Holder?
The AA-1612 is ideal for workshops, tool rooms, and inspection departments that require a stable, non-magnetic solution for holding dial test indicators. Its compact 8mm x 40mm arm is perfect for setups with limited space.
How does the Crystal holder compare to other brands?
Crystal is a well-regarded Indian brand known for its quality and value. While premium international brands might offer more features, Crystal provides excellent reliability and accuracy for its price point, making it a popular choice in the Indian B2B market.
What is the difference between a test indicator holder and a magnetic base?
A test indicator holder is a general term for a device that holds an indicator. A magnetic base is a type of holder that uses a powerful magnet to attach to ferrous surfaces. This model, the AA-1612, is a non-magnetic stand.
How to ensure the accuracy of measurements using this holder?
To ensure accuracy, place the holder on a clean, flat, and stable surface. Ensure the indicator stem is securely clamped in the holder and that all locking mechanisms are tightened before taking a measurement.
