Crystal Sine Vice AA-6141
Crystal Sine Vice Series AA-614 provides compact workholding solutions designed for smaller milling tasks and precision grinding applications. This unit features a 150 x 48 x 88 mm frame with a 0-75 mm jaw opening capacity. • Compact design for limited workspace • 0-75 mm jaw capacity for smaller parts • Stable alignment for precision grinding
Specifications
For: AA-6141- Series
- AA-614
- JAW opening
- 0-75mm
- Size
- 150 x 48 x 88 mm
- C.D. 'S' (Centre Dist.)
- 125 mm
Configurations
Click a row to switch| Variant | Series | JAW opening | C.D. 'S' (Centre Dist.) | Size | Price |
|---|---|---|---|---|---|
| AA-6141 | AA-614 | 0-75mm | 125 mm | 150 x 48 x 88 mm | ₹13,082 |
| AA-6142 | AA-614 | 0-90 mm | 150 mm | 180 X 63 X 98 mm | ₹17,682 |
| AA-6143 | AA-614 | 0-100 mm | 175 mm | 200 X 73 X 108 mm | ₹20,737 |
| AA-6144 | AA-614 | 0-125 mm | 200 mm | 235 X 96 X 130 mm | ₹27,793 |
Common Questions
Q: Can this vice be used on magnetic chucks? A: Yes, it serves as a reliable master reference fixture on toolroom magnetic chucks. Q: What is the maximum jaw opening capacity? A: Flexible jaw openings range up to a maximum holding capacity of 0-125 mm. Q: How does the pull-type design benefit operations? A: It minimizes jaw tilt and prevents workpiece lifting during heavy operations.
Maintenance Guidelines
- Wipe down working faces after use to prevent rust formation
- Apply light oil to screw mechanism for smooth operation
- Keep side slots clean to ensure proper mounting alignment
- Avoid overtightening to maintain jaw parallelism over time
- Store in dry conditions to preserve hardened steel integrity
- Regular inspection ensures continued precision accuracy
Industrial Applications
- Securely holding components for tight-tolerance surface grinding
- Ideal for light milling or EDM operations requiring precision
- Serves as a reliable master reference fixture on surface tables
- Compatible with toolroom magnetic chucks during metrology inspections
- Suitable for squaring and locking parts before machining
- Supports various industrial manufacturing workflows
Operational Performance
- Pull-type downward locking force minimizes jaw tilt during operation
- Prevents workpiece lifting during heavy grinding or milling tasks
- Consistent clamping force reduces part deformation risks
- Standard fitment for precision grinding setups
- Reduces setup time with intuitive side slot mounting
- Supports various industrial manufacturing workflows
Capacity & Dimensions
- Total body dimensions available from 150 x 48 x 60 mm up to 235 x 96 x 96 mm
- Flexible jaw openings ranging from 0-75 mm up to a maximum holding capacity of 0-125 mm
- Series AA - 614 offers consistent performance across size variants
- Ensures secure holding for small to mid-sized components
- Maintains stability under varying load conditions
- Designed for high-accuracy environments requiring repeatable results
Construction & Design
- Precision toolmaker's vice with rear-facing mechanical pull-down screw design
- High-accuracy box profile featuring fully enclosed screw mechanism
- Dual horizontal side slots provided for easy mounting setup
- Uniformly hardened tool steel precision ground on all working faces
- Guarantees extreme squareness and parallelism for accurate workholding
- Smooth mechanical screw drive delivers dependable clamping
- Prevents exposed thread wear for long-term reliability
More questions buyers ask
What is a Crystal Sine Vice used for?
A Crystal Sine Vice is a precision workholding device used in milling, grinding, and inspection to accurately set and hold a workpiece at a specific angle.
What are the main features of the Series AA-614 Sine Vice?
The Series AA-614 features high-grade steel construction, a fine adjustment mechanism for precise angular positioning, hardened jaws for durability, and a parallel ground base for accurate alignment on machine tables.
What material is the Crystal AA-614 Sine Vice made from?
The vice is constructed from high-grade, hardened steel to ensure long-term durability, resist wear and tear, and maintain accuracy under heavy loads.
How do I ensure the accuracy of the sine vice?
Accuracy is ensured by using precision gauge blocks to set the desired angle. The vice's own precision-ground surfaces and fine adjustment mechanism help in achieving and maintaining this accuracy.
Is the Crystal Sine Vice compatible with my milling machine?
Yes, the sine vice is designed with a standard parallel ground base, making it compatible with most standard T-slot machine tables on milling and grinding machines.
What is the warranty on the Crystal Sine Vice AA-614 series?
All Crystal products are backed by a standard manufacturer's warranty against manufacturing defects. We provide a GST invoice for your purchase to validate the warranty.
Do you offer pan-India delivery for the Sine Vice?
Yes, we offer reliable, pan-India delivery for the Crystal Sine Vice and all our other products. Your order will be shipped securely to your workshop or factory anywhere in India.
Can I get a GST invoice for my purchase?
Absolutely. We provide a proper GST invoice with every purchase, which you can use for input tax credit.
How do I maintain the Crystal Sine Vice for long life?
To ensure a long operational life, regularly clean the vice, apply light oil to sliding surfaces to prevent rust, inspect the jaws for wear, and avoid over-tightening the clamping mechanism.
What are the advantages of using a precision sine vice?
The main advantage is the ability to perform highly accurate angular machining and inspection, which is difficult to achieve with standard vices. This reduces setup errors, improves workpiece quality, and minimizes vibration.
Who should choose the Crystal Sine Vice model AA-6141?
The AA-6141 is the most compact and affordable model in the series. It is the perfect choice for small workshops, hobbyists, or for tasks involving smaller workpieces that require high precision on a budget.
Who should choose the Crystal Sine Vice model AA-6142?
Model AA-6142 offers a balanced combination of size, capacity, and price. It is a versatile workhorse for general-purpose milling and grinding in job shops and medium-sized manufacturing units.
Who should choose the Crystal Sine Vice model AA-6143?
The AA-6143 is designed for more demanding applications that require holding larger workpieces. Its increased jaw opening makes it suitable for industrial workshops that handle a variety of component sizes.
Who should choose the Crystal Sine Vice model AA-6144?
As the largest model in the series, the AA-6144 is built for heavy-duty industrial use. It is the best choice for large-scale manufacturing environments where maximum clamping capacity and robustness are required.
What is the main difference between the AA-6141 and AA-6142 models?
The primary difference is size and capacity. The AA-6142 has a larger jaw opening and overall dimensions compared to the more compact AA-6141, allowing it to hold bigger workpieces.
How do the jaw opening sizes compare across the AA-614 series?
The jaw opening increases with each model number in the AA-614 series. The AA-6141 has the smallest opening, while the AA-6144 has the largest, accommodating a progressively wider range of workpiece sizes.
Which Crystal Sine Vice model offers the best value for a small workshop?
For a small workshop, the AA-6141 or AA-6142 models typically offer the best value. The AA-6141 is ideal for budget-conscious buyers with smaller work, while the AA-6142 provides more versatility for a modest increase in price.
