Specifications
| Variant | Price | Admit Between Centers | Center Height | Bed Width | Spindle Bore | Range of Speed |
|---|---|---|---|---|---|---|
| 4'-6" Spindle Bore 52 mm | ₹1,72,000.00 | 650 mm | 215 mm | 280 mm | 52 mm | 46-550 rpm |
| 6' Spindle Bore 52 mm | ₹1,86,000.00 | 980 mm | 215 mm | 280 mm | 52 mm | 46-550 rpm |
| 6' Spindle Bore 80 mm | ₹1,98,000.00 | 980 mm | 250 mm | 280 mm | 80 mm | 46-550 rpm |
Construction & Stability
• Swing Over Bed 480 mm supports substantial workpiece diameters
• Center Height 250 mm defines standard mounting elevation
• Weight-approx 900 Kgs indicates robust foundation for vibration control
• Admit Between Centers 980 mm allows for extended workpiece lengths
• Swing Over Gap 680 mm facilitates large diameter turning tasks
Tooling & Accessories
• Tail Stock dia 50 mm provides stable rear support for drilling
• Spindle Taper Head Stock MT6 ensures secure tool holder mounting
• Spindle Taper Tail Stock MT4 matches standard accessory interfaces
• Swing Over Cross Slide 375 mm offers adequate tool post clearance
• Quill Travel 139 mm enables deep drilling and boring operations
Performance Specifications
• Range of speed 46-550 rpm offers flexibility for various materials
• TPI Thread 4-48 TPI allows for precise thread cutting operations
• Spindle Bore 80 mm accommodates larger bar stock feeding
• No of Spindle Speed 6 Nos provides distinct gear ratios for efficiency
• Lead-screw-tpi 32/4 TPI ensures accurate lead screw engagement
Core Capabilities
• Engineered for reliable metal removal in industrial workshops
• Belt driven medium duty design ensures consistent power transmission
• Supports versatile turning operations with high speed range
• Dual metric and TPI threading capabilities handle complex screw production
• 280 mm bed width provides rigid support for heavy machining loads
Applications & FAQ
• Suitable for tool rooms requiring precision and durability
• Ideal for fabrication centers seeking durable industrial lathe equipment
• Handles complex screw production with metric-thread 0.5-7 mm
• Bed Length 1825mm / 6' supports long shaft machining requirements •
Q: Is this machine suitable for heavy-duty continuous operation? •
A: Yes, the belt driven medium duty design supports sustained industrial use.
Q: What maintenance is required for the spindle bearings?
A: Regular lubrication and inspection ensure long-term spindle performance.
Q: Can this lathe handle both metric and imperial threading?
A: Yes, it features dual metric and TPI threading capabilities for versatility.
